DIN 3A SMS TP304 Stainless Steel Valves Electric Actuated Tri - Clamp Butterfly Valve
DIN 3A SMS TP304 Stainless Steel Valves Electric Actuated Tri - Clamp Butterfly Valve
DIN 3A SMS TP304 Stainless Steel Valves Electric Actuated Tri - Clamp Butterfly Valve
DIN 3A SMS TP304 Stainless Steel Valves Electric Actuated Tri - Clamp Butterfly Valve
Specifications
Brand Name :
KAYSUNS
Model Number :
KS-SV
Certification :
PED,ISO
Place of Origin :
China
MOQ :
10Pcs
Price :
USD
Supply Ability :
400Tons per Month
Delivery Time :
30-45days
Packaging Details :
Plywood Boxes
Type :
Tri-Clamp Butterfly Valve
Material :
304, 316L, 1.4301, 1.4404 etc.
Size :
DN25-DN100
Sealing :
EPDM
Standard :
ISO, DIN, SMS, 3A, etc.
Connection :
Welding, Threaded, Clamped, etc.
Description

DIN 3A SMS TP304 Stainless Steel Sanitary Valves - Electric Actuated Tri-Clamp Butterfly Valve

Electric actuated sanitary tri-clamp butterfly valve is electric actuator operated sanitary butterfly valves with tri-clamped ends. We provides full line of electric tri-clamp butterfly valve from 1/2″ to 8″ in stainless steel T304, T316L etc. The electric actuator can be selected upon client’s request, either of China origin or EU/USA brand. Sanitary butterfly valve is our strength sanitary valves , it comply with 3A, DIN, SMS, ISO, DS standards etc, with excellent precision and high purity surface. Wellgreen is your reliable partner for processing controlling of Food, Brewery, Beverage, Dairy, Pharmaceutical etc.

Strengths:

  • Forged valve body – stainless steel T304, T316L.
  • Simple and robust design.
  • Low pressure losing.
  • Renewable design of valve body.
  • Every connection of flanged, butt welded, tri-clamp, threaded etc.
  • Different series of DIN, 3A, SMS, ISO, IDF, RJT, DS on request.
  • Electric actuator brand on request.
  • Sealing materials conform to FDA 177.2600.

Parameter of Electric Actuator:

  • Protection degree: IP-67.
  • Environment temperature: -2°C ~ 60°C (other temperature can be custom made).
  • Installment angle: any angle.
  • Material of body: aluminum alloy diecasting.
  • Features optional: torque than the protection, heated dehumidifier, over-heat protection.
  • Hand operation: by detachable hexagon.
  • Spacing: electrically: completely close and open limit switch.
  • Manually: link stopper.
  • Input signal: 4-20mA.DC, 1-5V.DC, 0-10V.DC (other signals can be chose before leaving factory).
  • Output signal: 4-20m A.DC, 0-10V.DC (other signals can be chose before leaving factory).
  • Voltage: AC.24V 110V 220V 380V DC.24V Frequency: 50HZ,60 HZ.
  • Type of control: on-off indicator light, passive contact point, opening position, intelligent control
  • Switching time(S): 9,10,13,15,20,25,30,50,60,1000.

Application:

Pharmacy, Beer, Food, BioPharm, Dairy, Beverage, Biotech, Cosmetics etc.

Electric Actuated Sanitary Tri-Clamp Butterfly Valves Specification
PRODUCT Electric Actuated Sanitary Tri-Clamped Butterfly Valve
DIMENSION 1/2″ ~ 8″
MATERIAL T304, T316L, 1.4301, 1.4404 etc.
STANDARD 3A, DIN, SMS, ISO, ISO, DS etc.
SEALING GASKET EPDM, NBR, FPM, Silicone etc.
TEMPERATURE -2°C / 28.4°F up to +60°C/ +140°F
PRESSURE 0.2 – 10bar
CONNECTION Tri-clover Ends
OPERATION Electric actuator
APPLICATION Pharmacy, Beer, Food, Petroleum, Dairy, Beverage,Biotech ,Cosmetics etc.
How to order

*Part Name

*Size

*Material

*Quantity

*Standard

DIN 3A SMS TP304 Stainless Steel Valves Electric Actuated Tri - Clamp Butterfly Valve

Dimension of Electric Actuated Tri-Clamp Butterfly Valve -DIN Series

SIZE A H H1 D1 L*W
DN10 68 141 41 34 162*115
DN15 68 141 41 34 162*115
DN20 68 141 41 34 162*115
DN25 68 141 41 50.5 162*115
DN32 68 141 41 50.5 162*115
DN40 68 141 41 50.5 162*115
DN50 76 141 55 64 162*115
DN65 80 141 64 91 162*115
DN80 86 141 71 106 162*115
DN100 90 141 81 119 208*122
DN125 118 153 116 144.5 208*122
DN125 118 153 116 155 208*122
DN150 140 153 136 167 208*122
DN150 140 153 136 183 208*122
DN200 158 153 171 217.4 208*122
DN200 158 153 171 233.5 208*122

DIN 3A SMS TP304 Stainless Steel Valves Electric Actuated Tri - Clamp Butterfly Valve

Dimension of Electric Actuated Tri-Clamp Butterfly Valve -3A, SMS, ISO, DS Series

SIZE A H H1 D1 L*W
1/2″ 68 141 41 25.4 162*115
3/4″ 68 141 41 25.4 162*115
1″ 68 141 41 50.5 162*115
11/4″ 68 141 41 50.5 162*115
11/2″ 68 141 45 50.5 162*115
45 76 141 47 64 162*115
48 76 141 49 64 162*115
2″ 76 141 53 64 162*115
57 76 141 55 77.5 162*115
21/2″ 80 141 59 77.5 162*115
3″ 80 141 66 91 162*115
3.5″ 84 141 71 106 162*115
4″ 90 141 79 119 162*115
108 90 153 81 119 162*115
114 90 153 81 130 162*115
5″ 118 153 116 144.5 208*122
133 118 153 116 155 208*122
6″ 140 153 136 167 208*122
159 140 153 136 183 208*122
168.3 140 153 136 183 208*122
8″ 150 153 171 217.4 208*122
219 150 153 171 233.5 208*122

*All dimension are in mm except specified.

For more information, please contact us.
