0.25mm - 28mm Wall Thickness Stainless Steel Welded Tube For Boiler / Gas Transport
0.25mm - 28mm Wall Thickness Stainless Steel Welded Tube For Boiler / Gas Transport
0.25mm - 28mm Wall Thickness Stainless Steel Welded Tube For Boiler / Gas Transport
0.25mm - 28mm Wall Thickness Stainless Steel Welded Tube For Boiler / Gas Transport
0.25mm - 28mm Wall Thickness Stainless Steel Welded Tube For Boiler / Gas Transport
0.25mm - 28mm Wall Thickness Stainless Steel Welded Tube For Boiler / Gas Transport
0.25mm - 28mm Wall Thickness Stainless Steel Welded Tube For Boiler / Gas Transport
0.25mm - 28mm Wall Thickness Stainless Steel Welded Tube For Boiler / Gas Transport
Specifications
Brand Name :
MTSCO
Model Number :
MTSCOSSWT15
Certification :
ISO 9001 & PED & AD2000
Place of Origin :
CHINA
MOQ :
negotiable
Price :
2500-12000USD/TON
Payment Terms :
T / T ; L / C
Supply Ability :
500 Tons / Month
Delivery Time :
25 Days
Packaging Details :
Plywood Case / Bundles
Material :
TP304 TP304L TP316 TP316L，1.4306 / 1.4404
Surface :
320 # Or 400 # Outside Polished
Delivery Condition :
Soft / Hard
Type :
Welded
Process Method :
ERW , EFW Etc
PMI Test :
100%
Description

ASTM A249 1.4306 / 1.4404 Stainless Steel Welded Tube For Boiler

ASTM A249 Standard :

Size OD Nominal Wall Outside Diameter Length Wall
1/2" (12.7) 0.065" (1.65)/0.049" (1.25) +/-0.005 (0.13) +1/8" (3.18) - 0 +/-10.0%
3/4" (19.1) 0.065" (1.65)/0.049" (1.25) +/-0.005 (0.13) +1/8" (3.18) - 0 +/-10.0%
1" (25.4) 0.065" (1.65)/0.049" (1.25) +/-0.005 (0.13) +1/8" (3.18) - 0 +/-10.0%
1-1/2" (38.1) 0.065" (1.65)/0.049" (1.25) +/-0.008" (0.20) +1/8" (3.18) - 0 +/-10.0%
2" (50.8) 0.065" (1.65)/0.049" (1.25) +/-0.008" (0.20) +1/8" (3.18) - 0 +/-10.0%
2-1/2" (63.5) 0.065" (1.65) +/-0.010" (0.25) +1/8" (3.18) - 0 +/-10.0%
3" (76.2) 0.065" (1.65) +/-0.010" (0.25) +1/8" (3.18) - 0 +/-10.0%
4" (101.6) 0.083" (2.11) +/-0.015" (0.38) +1/8" (3.18) - 0 +/-10.0%
6" (152.4) 0.083" (2.11) +/-0.030" (0.76) +1" (25.4) - 0 +/-10.0%
6" (152.4) 0.109" (2.77) +/-0.030" (0.76) +1" (25.4) - 0 +/-10.0%
8" (203.2) 0.109" (2.77) +0.061" (1.55)/-0.031" (0.79) +1" (25.4) - 0 +/-10.0%

Item Description
Basic Information Material Grade TP304, TP304L, TP304H, TP316, TP316L, TP316Ti, TP309S, TP310S, TP321, TP321H, TP347, TP347H, etc
Outer Diameter 5.80mm-2032mm (0.23" to 80")
Wall Thickness 0.25mm-28mm (0.01" to 1.125")
Length Normally fixed length 6m, can as per customer’s requirement
Standard ASTM A312; ASTM A269; ASTM A789; ASTM A790 ect.
Process Method ERW, EFW etc
Industry & Advantage Application a) For fluid and gas transport
b) Structure and machining
c) Heat exchanger pipes etc
Advantages a) Superior surface finish
b) Better mechanical property
c) More precise dimension
d) Perfect inspection method and inspection equipment
Terms & Conditions Price Item FOB, CFR, CIF or as negotiation
Payment T/T, LC or as negotiation
Delivery Time 30 working days after received your deposit (Normally according to the order quantity)
Package Iron case; woven bag or as per customer’s requirement
Quality Requirement Mill Test Certificate will be supplied with shipment, Third Part Inspection is acceptable
Quality Test X-ray, Size test, Length test
Chemical Analysis(Photoelectric Emission Spectroscopic) etc
Market Main Market Europe, Middle East, Southeast Asia, South America. Etc
