ASME B16.11 F11 / F22 Stainless Steel Socket Welded / Threaded Boss 2000LBS For Connection
ASME B16.11 F11 / F22 Stainless Steel Socket Welded / Threaded Boss 2000LBS For Connection
ASME B16.11 F11 / F22 Stainless Steel Socket Welded / Threaded Boss 2000LBS For Connection
ASME B16.11 F11 / F22 Stainless Steel Socket Welded / Threaded Boss 2000LBS For Connection
Specifications
Brand Name :
MTSCO
Model Number :
MTSCOFHPF09
Certification :
ISO 9001 & PED & AD2000
Place of Origin :
CHINA
MOQ :
negotiable
Price :
6000-17000USD/TON
Payment Terms :
T / T ; L / C
Supply Ability :
300 Tons / Month
Delivery Time :
30 Days
Packaging Details :
Plywood Case
Material :
F304/304l/316/316l/310s/309s/317l
Surface :
Pickling,Galcanized or Black
Type :
Socket-welded, Threaded, Butt-welding
Package :
Plywood case
Applications :
connection
Standard :
ASME B16.11
Description

ASME B16.11 F11 / F22 Stainless Steel Socket Welded / Threaded Boss 2000LBS For Connection

1 . Commodity: Elbow, Tee, Coupling, Half coupling, Cap, Plug, Bushing, Union, Out-let, Swage nipple, Bullplug, Reducer insert, Hex nipple, Street elbow, Boss, etc.
2 . Process Method : Forged
3 . Materials : Stainless Steel ,Carbon steel, etc
4 . Standards : ASME / ANSI B16.1, ASTM A105, A305LF2, A106, A312, A234, A403,etc.
5 . Size Range : NPS 1 / 8 inch- 4 inch
6 . Tolerances : according to the specification or customer’s request and drawings
7 . Applications : oil & gas industry , chemical industry , electric power , boiler and heat exchanger , machinery , metallurgy , sanitary construction etc .

TYPE:

A:Elbow, Tee, Coupling, Half coupling, Cap, Plug, Bushing, Union, Out-let, Swage nipple, Bullplug, Reducer insert, Hex nipple, Street elbow, Boss, etc.

Socket-welded, Threaded ( NPT or PT type).

B: Butt-welding

SIZE: NPS 1 / 8 inch- 4 inch

RATING:

Pressure: Threaded end: 2000/3000/6000 LBS

Socket-welded end: 3000/6000/9000 LBS

Butt welded end: Sch40/Sch80/Sch160/XXS

MARKING:

A. Carbon and alloy steel: Marked by stamping.

B. Stainless steel: Marked by electro-etched, jetprinted or stamping.

C. 3/8 inch under: Brand only

D. 1/2 inch to 4 inch: Marked with brand, material, heat B16 (for ASME B16.11 product), pressure and size.

FINISHING: Carbon steel: Galcanized or Black

Stainless steel: Pickled

Price Item:FOB , CFR , CIF or as negotiation

Payment:T/T, LC or as negotiation

Delivery Time :30 working days after received your deposit ( Normally according to the order quantity )

Package:Cartion/wooden case,Plywooden case

Quality Requirement:Mill Test Certificate will be supplied with shipment , Third Part Inspection is acceptable

Test:

NTD ( Ultrasonic test , Eddy Current test )

Mechanical Test ( Tension Test , Flaring Test , Flattening Test , Hardness Test , Hydraulic test )

Metal Test ( Metallographic Analysis , Impact Test - High / low temperature )

Chemical Analysis ( Photoelectric Emission Spectroscopic )

ASME B16.11 F11 / F22 Stainless Steel Socket Welded / Threaded Boss 2000LBS For Connection


MTSCO is a leading manufacturer who is specialized in stainless steel seamless pipes , bright annealed tubes , seamless coiled tubing etc . In order to facilitate customers , we have pipe fittings and flanges too . MTSCO has the most advanced producing and testing equipment . We can totally satisfy your requirement .
