Specifications
Brand Name :
MTSCO
Model Number :
MTSCOSSCT06
Certification :
ISO 9001 & PED
Place of Origin :
CHINA
MOQ :
negotiable
Price :
5500-10000USD/TON
Payment Terms :
T / T ; L / C
Supply Ability :
300 Tons / Month
Delivery Time :
30 Days
Packaging Details :
Iron Case / Plywood Case
Material :
SS316L / DIN1.4404 / SS304L / DIN1.4306 / SS310S / DIN1.4845
Standard :
ASTM A269 / ASTM A213 Dual Standards Etc
Delivery Condition :
Soft / Hard
Every Coil :
About 30Kgs Per / Coil
Type :
Seamless
Surface :
Bright Annealed / Pickled
Description

20BWG 0.89mm Wall Thickness ( WT ) Stainless Steel Coiled Tubing ASTM A213 Standard

MTSCO is a leading manufacturer who is specialized in seamless coiled tubing produce . Stainless steel seamless coiled tubing final surface is bright annealed. According to standard very strictly, tubes which produced by us always have correct OD and WT tolerance. They are very popular in military, semiconductor, pharmaceutical biotechnology, precision instruments, hydraulic parts, chemicals industry, boilers and heat exchangers, aerospace industry, automotive industry, electronics, petroleum exploration, precision machinery, rail transportation, shipbuilding plants, air-conditioning industry, solar industry, water heater industry etc. They can be used in many others industries also .

Where the coiled tubing used ?

1 . Control tubing in oil and gas well
2 . Instrument tubing
3 . Chemicl injection tubing line
4 . Pre-insulated tubing
5 . Electric heating or steam heating tubing line
6 . Hater tubing line

Chemical Composition :

Material ASTM A269 Chemical Composition % Max
C Mn P S Si Cr Ni Mo N B Nb Ti
TP304 0.08 2 0.045 0.03 1 18.0-20.0 8.0-11.0 ^ ^ ^. ^
TP304L 0.035 2 0.045 0.03 1 18.0-20.0 8.0-12.0 ^ ^ ^ ^
TP316 0.08 2 0.045 0.03 1 16.0-18.0 10.0-14.0 2.00-3.00 ^ ^ ^
TP316L 0.035 D 2 0.045 0.03 1 16.0-18.0 10.0-15.0 2.00-3.00 ^ ^ ^
TP321 0.08 2 0.045 0.03 1 17.0-19.0 9.0-12.0 ^ ^ ^ 5C -0.70
TP347 0.08 2 0.045 0.03 1 17.0-19.0 9.0-12.0 　 　 10C -1.10 ^

Material Heat treatment Temperure F (C) Min. Hardness
Brinell Rockwell
TP304 Solution 1900 (1040) 192HBW/200HV 90HRB
TP304L Solution 1900 (1040) 192HBW/200HV 90HRB
TP316 Solution 1900(1040) 192HBW/200HV 90HRB
TP316L Solution 1900(1040) 192HBW/200HV 90HRB
TP321 Solution 1900(1040) F 192HBW/200HV 90HRB
TP347 Solution 1900(1040) 192HBW/200HV 90HRB
OD, inch OD Tolerance inch(mm) WT Tolerance % Length Tolernace inch(mm)
+ -
≤ 1 / 2 ± 0.005 ( 0.13 ) ± 15 1 / 8 ( 3.2 ) 0
> 1 / 2 ~1 1 / 2 ± 0.005(0.13) ± 10 1 / 8 (3.2) 0
> 1 1 / 2 ~< 3 1 / 2 ± 0.010(0.25) ± 10 3 / 16 (4.8) 0
> 3 1 / 2 ~< 5 1 / 2 ± 0.015(0.38) ± 10 3 / 16 (4.8) 0
> 5 1 / 2 ~< 8 ± 0.030(0.76) ± 10 3 / 16 (4.8) 0
8~< 12 ± 0.040(1.01) ± 10 3 / 16 (4.8) 0
12~< 14 ± 0.050(1.26) ± 10 3 / 16 (4.8) 0
