Hydraulic Testing Cold Drawn Stainless Steel Seamless Tube Standard ASTM A213
Hydraulic Testing Cold Drawn Stainless Steel Seamless Tube Standard ASTM A213
Hydraulic Testing Cold Drawn Stainless Steel Seamless Tube Standard ASTM A213
Hydraulic Testing Cold Drawn Stainless Steel Seamless Tube Standard ASTM A213
Hydraulic Testing Cold Drawn Stainless Steel Seamless Tube Standard ASTM A213
Hydraulic Testing Cold Drawn Stainless Steel Seamless Tube Standard ASTM A213
Hydraulic Testing Cold Drawn Stainless Steel Seamless Tube Standard ASTM A213
Hydraulic Testing Cold Drawn Stainless Steel Seamless Tube Standard ASTM A213
Specifications
Brand Name :
MTSCO
Model Number :
MTSCOSSST19
Certification :
ISO 9001 & PED
Place of Origin :
CHINA
MOQ :
negotiable
Price :
4300-9800USD/TON
Payment Terms :
T / T ; L / C
Supply Ability :
300 Tons / Month
Delivery Time :
30 Days
Packaging Details :
Iron Case / Plywood Case
Material :
300 Series , 904L , Nickel Alloy Etc
Thickness :
AW ( Average Wall Thickness )
Technology :
Cold Drawn / Cold Rolled
Length :
Random Length
Surface :
Pickling & Annealing
Inner :
Clean
Description

Hydraulic Test Of Stainless Steel Seamless Tube , Pickling , Standard ASTM A213

ASTM A312 / A312M

Elements 304L(wt%) 316L (wt%)
(C) Carbon, max 0.035 0.035
(Mn) Manganese, max 2 2
(P) Phosphorus, max 0.045 0.045
(S) Sulfur, max 0.03 0.03
(Si) Silicon, max 1 1
(Ni) Nickel 8.0 - 13.0 10.0 - 14.0
(Cr) Chromium 18.0 - 20.0 16.0 - 18.0
(Mo) Molybdenum N/A 2.0 - 3.0
(Fe) Iron Bal. Bal.
(Cu) Copper N/A N/A
(N) Nitrogen N/A N/A

Birmingham Wire Gauge BWG
　 Wall Thickness 　 Wall Thickness
BWG IN MM BWG IN MM
0 0.340 8.64 19 0.042 1.07
1 0.300 7.62 20 0.035 0.89
2 0.284 7.21 21 0.032 0.81
3 0.259 6.58 22 0.028 0.71
4 0.238 6.05 23 0.025 0.64
5 0.220 5.59 24 0.022 0.56
6 0.203 5.16 25 0.020 0.51
7 0.180 4.57 26 0.018 0.46
8 0.165 4.19 27 0.016 0.41
9 0.148 3.76 28 0.014 0.36
10 0.134 3.40 29 0.013 0.33
11 0.120 3.05 30 0.012 0.30
12 0.109 2.77 31 0.010 0.25
13 0.095 2.41 32 0.009 0.23
14 0.083 2.11 33 0.008 0.20
15 0.072 1.83 34 0.007 0.18
16 0.065 1.65 35 0.005 0.13
17 0.058 1.47 36 0.004 0.10
18 0.049 1.24 　 　

　

Stanard Wire Gauge ( Fomerly Imperial Wire Gauge ) SWG
SWG Wall Thickness SWG Wall Thickness
0 0.324 8.23 21 0.032 0.81
1 0.3 7.62 22 0.028 0.71
2 0.276 7.01 23 0.024 0.61
3 0.252 6.4 24 0.022 0.56
4 0.232 5.89 25 0.02 0.51
5 0.212 5.38 26 0.018 0.46
6 0.192 4.88 27 0.0164 0.42
7 0.176 4.47 28 0.0148 0.38
8 0.16 4.06 29 0.0136 0.35
9 0.144 3.66 30 0.0124 0.31
10 0.128 3.25 31 0.0116 0.29
11 0.116 2.95 32 0.0108 0.27
12 0.104 2.64 33 0.01 0.25
13 0.092 2.34 34 0.0092 0.23
14 0.08 2.03 35 0.0084 0.21
15 0.072 1.83 36 0.0076 0.19
16 0.064 1.63 37 0.0068 0.17
17 0.056 1.42 38 0.006 0.15
18 0.048 1.22 39 0.0052 0.13
19 0.04 1.02 40 0.0048 0.12
20 0.036 0.91 　 　

　

MTSCO has 26 cold-drawing production lines. And the annual production capacity is 5000 tons, the annual GDP is more than 30 million USD.

1 . Seamless tube : small diameter seamless overlength coiled tubing , bright annealed tube , inside and outside polished tube , heat exchanger tube , U-bent tube , the products all adopt the most advanced technology , with 26 production lines .

2 . Seamless pipe : MTSCO has 8 production lines for stainless steel cold drawn pipe , 10 production lines for cold roll pipe .

3 . Other Products : Stainless steel welded pipe , flange and fitting are our relevant products , for providing our clients the supplied solutions of the pipeline projects .

Hydraulic Testing Cold Drawn Stainless Steel Seamless Tube Standard ASTM A213
