High Pressure Bead Blasting Equipment for Complex Workpieces Clean Model
High Pressure Bead Blasting Equipment for Complex Workpieces Clean Model
High Pressure Bead Blasting Equipment for Complex Workpieces Clean Model
High Pressure Bead Blasting Equipment for Complex Workpieces Clean Model
Specifications
Brand Name :
Stelle
Model Number :
STR-9060
Certification :
CE ISO
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
20 UNITS PER MONTH
Delivery Time :
15 DAYS AGAINST PAYMENT
Packaging Details :
BY STRONG WOODEN CASE
Name :
abrasive blasting machine
Type :
High Pressure
Function :
Cabinet
Dust Removal :
Dustless
Application :
Model / Complex Workpieces
Nozzle :
Boron Carbide Nozzle
Description

High-Pressure Automatic Sandblasting Cabinet for Complex Workpieces / Clean Model

Product Introduction

For small and medium-sized, small and medium-sized general parts and high hardness of the workpiece rapid blasting

Technical Features:

Dimension size:900*1350(including dust box)*1900(mm)

Working chamber size: 900*800*800(L*W*H mm)

Dust box size: 430*430*1600(L*W*H mm)

Dusting fan power: 0.55kw

Dust removal method: bag pulse dust

Lighting: LED 18W lamp 1 pcs

Spray gun: high-pressure spray gun-1pcs

Nozzle: boron carbide nozzle-1pcs

Shell: 2.0mm cold-rolled steel plate welded

Observation window: 1230* 420(mm)

Pressure tank: diameter 350mm *high 450mm

Pressure gauge: 2 pieces Regulator: 1 pcs 1 pcs

Dust valve: Working door size: 630mm * 630mm Air pressure requirements: 5 ~ 8bar (kg / cm2) must be greater than 2 cubic meters of air compressor supporting

Abrasive Blasting Machine Application :

clean cast parts, heat treatment pieces, burrs, residues, you can light decorated its surface, pre-plating; Especially for sprayed steel grit, glass sand; do not recommend the use of steel balls, grit and other large intensity of the sandblasting material
