CB/T493-98 MARINE AIR CYLINDERS, MARINE LOW-PRESSURE AIR CYLINDERS OVERVIEW OF MAIN USES:

The air cylinders on board can be divided into: marine main engine start air cylinder CB493-98, marine auxiliary engine start air cylinder CB493-98, marine auxiliary engine start air cylinder CB493-98, and marine engine start air cylinder CB493-98 marine control air Bottle CB493-98, marine air cylinder CB493-98, marine whistle air cylinder CB493-98, marine whistle buffer air cylinder CB493-98 marine whistle, miscellaneous air cylinder CB493-98, emergency marine generator start air cylinder, The main engine remote control air bottle CB493-98 and so on. But its main function is to store compressed air for the ship's main and auxiliary engines to start or sound the siren, and other purposes.

CB/T493-98 MARINE AIR CYLINDER, DESIGN CONDITIONS OF MARINE LOW-PRESSURE AIR CYLINDER:

MARINE MAIN ENGINE START AIR CYLINDER, MARINE START BUFFER AIR CYLINDER CB/T493-98 THE MAIN COMPONENTS, MATERIALS AND FUNCTIONS OF THE EQUIPMENT:

2.1 Marine air cylinders, marine low-pressure air cylinders (including: marine main engine start air cylinder CB493-98, marine auxiliary engine start air cylinder CB493-98, marine auxiliary engine start air cylinder CB493-98, marine engine start air cylinder CB493-98 Control air cylinder CB493-98, marine miscellaneous air cylinder CB493-98, marine whistle air cylinder CB493-98, marine whistle buffer air cylinder CB493-98 marine whistle, miscellaneous air cylinder CB493-98, emergency marine generator start air Bottle, the main engine remote control air bottle CB493-98) Equipment composition:

The gas cylinder consists of a gas cylinder body, a cylinder head valve, a safety valve, an intake stop valve, a liquid discharge stop valve, a pressure gauge valve, a hand hole and a mounting base. The cylinder body material is Q245R. The intake valve, liquid discharge stop valve, and pressure gauge valve are made of cast steel or stainless steel.

2.2 CB/T493-98 marine air cylinders, marine low-pressure air cylinders (including: marine main engine starting air cylinder CB493-98, marine auxiliary engine starting air cylinder CB493-98, marine auxiliary engine starting air cylinder CB493-98, marine engine starting air Bottle CB493-98 Marine Control Air Cylinder CB493-98, Marine Miscellaneous Air Cylinder CB493-98, Marine Whistle Air Cylinder CB493-98, Marine Whistle Buffer Air Cylinder CB493-98 Marine Whistle, Miscellaneous Air Cylinder CB493-98, Emergency Main technical requirements for marine generator start air bottle, main engine remote control air bottle CB493-98

(A) The cylinder volume is 30L-5000L.

(B) The product standard is CB/T493-1998.

(C) Working pressure: 1.0MPa/3.0Mpa

(D) Working medium; air.

(E) Equipment classification: CCS/BV/GL/KR/LR/DNV/RS/NK, etc.

(D) Working medium; air.

FOUR, MARINE AIR CYLINDERS, MARINE LOW-PRESSURE AIR CYLINDERS CB/T493-98 RANDOM INFORMATION AND DOCUMENTS

1. Product qualification certificate, product material certificate

2. Product packing list

3. Classification society certificate

MARINE AIR CYLINDERS, MARINE LOW-PRESSURE AIR CYLINDERS TECHNICAL DOCUMENTS

1. Within one week after signing the contract, the seller will provide the buyer with two sets of approved materials. The buyer will return the approval opinions to the seller within one week after receiving the approval materials. The seller shall re-provide the second set of work materials to the buyer within one week after receiving the approval opinion.

2. Approval materials and work materials should include:

(1) Detailed equipment outline size installation drawing

(2) Equipment weight

(3) Base installation drawing

(4) List of materials and spare parts

QUALITY ASSURANCE REGULATIONS FOR MARINE AIR CYLINDERS AND MARINE LOW-PRESSURE AIR CYLINDERS

1. The seller organizes production and management in accordance with the ISO9000 standard certification or the quality management model recognized by the buyer.

2. Factory test and acceptance

①: Inspect and test in accordance with the test program approved by the buyer.

②: Before leaving the factory, notify the buyer one week in advance for the factory acceptance of the equipment.

③: Quality guarantee period: 12 months after the buyer's equipment is delivered for normal use.

• Service: The seller shall provide on-site technical guidance or operation training free of charge, and provide a training outline (including manuscripts and electronic documents). For quality problems arising during use and malfunctions caused by product quality during the warranty period, the seller shall be free Replacement or repair of parts within the time required by the three parties (the end user).

MARINE AIR CYLINDERS, MARINE LOW-PRESSURE AIR CYLINDERS PACKAGING AND DELIVERY SIGNS:

It shall comply with GB/T13384-92 "General Technical Requirements for Packaging of Mechanical and Electrical Products", shall be waterproof, dustproof and anti-collision, and shall be marked.

1. After passing the factory test, the equipment shall be cleaned and dried. Put the product instruction manual, ship inspection certificate and other random documents into the wooden box before packaging. The packaging is packed in wooden boxes. The packing box is lined with waterproof asphalt oil blanket.

2. Delivery mark: According to GB191-90 "Packaging, Storage and Transportation Graphical Marks".

Signs include: ①: equipment model, name, gross weight

②: The name, address, and department of the receiving unit.

③: The name, address, delivery department and delivery date of the shipper.

CB/T493-1998 MARINE AIR CYLINDERS, MARINE LOW-PRESSURE AIR CYLINDERS USUALLY SELECTION MARK

The volume of the marine air cylinder is 1000L, the working pressure is 3.0Mpa, and the installation form of the marine main engine start-up air cylinder is marked as:

Marine air cylinder A1.0-3.0 CB/T493-98; marine starting air cylinder A1.0-3.0 CB/T493-98; marine main engine starting air cylinder A1.0-3.0 CB/T493-98; marine auxiliary engine starting air Bottle A1.0-3.0 CB/T493-98; Marine engine start air bottle A1.0-3.0 CB/T493-98;

THE VOLUME OF THE MARINE AIR CYLINDER IS 160L, THE WORKING PRESSURE IS 3.0MPA, AND THE INSTALLATION FORM OF THE MARINE MAIN ENGINE START-UP AIR CYLINDER IS MARKED AS:

Marine air cylinder A0.16-3.0 CB493-98, marine control air cylinder A0.16-3.0 CB493-98, marine miscellaneous air cylinder A0.16-3.0 CB493-98, marine siren air cylinder A0.16-3.0 CB493- 98. Marine steam whistle buffer air cylinder A0.16-3.0 CB493-98 Marine whistle and miscellaneous air cylinder A0.16-3.0 CB493-98;

Marine air cylinder A0.08-1.0 CB493-98, A0.08-1.0 marine control air cylinder CB493-98, marine miscellaneous air cylinder A0.08-1.0 CB493-98, marine whistle air cylinder A0.08-1.0 CB493- 98. Marine siren buffer air cylinder A0.08-1.0 CB493-98 Marine siren, miscellaneous air cylinder A0.08-1.0 CB493-98,

"JINGJIANGSHI DONGXING MARINE FITTING WORKS

-COMPLETE QUALIFICATIONS":

It is a collection of marine air cylinders CB493-98, marine control air cylinders CB493-98, marine miscellaneous air cylinders CB493-98, marine whistle air cylinders CB493-98, marine whistle buffer air cylinders CB493-98 marine whistle, miscellaneous air cylinders CB493-98, marine main engine start air cylinder CB493-98, marine auxiliary engine start air cylinder CB493-98, marine engine start air cylinder CB493-98, emergency marine generator start air cylinder, main engine remote control air cylinder CB493-98 production and sales , Service as one manufacturer!
