High Resolution 2.4G Bluetooth Barcode Reader
High Resolution 2.4G Bluetooth Barcode Reader
High Resolution 2.4G Bluetooth Barcode Reader
High Resolution 2.4G Bluetooth Barcode Reader
High Resolution 2.4G Bluetooth Barcode Reader
High Resolution 2.4G Bluetooth Barcode Reader
High Resolution 2.4G Bluetooth Barcode Reader
High Resolution 2.4G Bluetooth Barcode Reader
High Resolution 2.4G Bluetooth Barcode Reader
High Resolution 2.4G Bluetooth Barcode Reader
Specifications
Brand Name :
Dingyu/ DY SCAN
Model Number :
DS5210B
Certification :
CE, ROHS, FCC, IEC, FDA
Place of Origin :
China
MOQ :
1
Price :
Negotiate
Payment Terms :
T/T, Paypal, Alibaba
Supply Ability :
10000pcs/month
Delivery Time :
3-7 days
Packaging Details :
Package Size :110*140*56mm
Communication way :
Wireless 2.4G, bluetooth
Power supply :
DC 5V@220mA(work)
Scan type :
CMOS
Light source :
Red light LED 625±10nm(aim),6500K LEDs(lighting)
Resolution :
1D：≥5mil，2D：≥8.7mil @PCS90%
Decoding speed :
25CM/S
Depth of field :
5mil：50~130mm，13mil：50~270mm
cup :
32 bit
Description

Handheld wireless 2.4g bluetooth barcode reader 1d 2d barcode scanner high resolution

High Resolution 2.4G Bluetooth Barcode Reader

Product Description:

DS5210B is a high-performance 2D wireless 2.4G bluetooth barcode scanner with leading CMOS image recognition technology.

It can easily read the paper, goods other media barcodes.

Widely used in courier, inventory management and other scenes.

Features:

☆ Read all mainstream 1D 2D barcodes in the market easily.(5mil)

☆ Ultra-low power consumption, continuous working time 16h.

☆ Bluetooth 4.2, intelligent automatic connection when it’s beyond range, not manual setting.

☆ Mode: Bluetooth(HID,SPP,BLE), wired, wireless 2.4G, connected with PC, mobile phone easily.

High Resolution 2.4G Bluetooth Barcode Reader

High Resolution 2.4G Bluetooth Barcode Reader

High Resolution 2.4G Bluetooth Barcode Reader

High Resolution 2.4G Bluetooth Barcode Reader

High Resolution 2.4G Bluetooth Barcode Reader

Parameter:

Scan Type CMOS
Light Source Red Light LED 525±10nm(aim), 5600K LED ( Lighting)
CPU 32-bit
Resolution 640*480
Resolution 1D:≥5mil,2D:≥8.7mil @PCS90%
Decoding speed 25CM/S
Depth of field 5mil:50~130mm,13mil:50~270mm
Scan Mode Manual , Auto Sense
Scan angle Roll:±360°,Pitch:±60°or greater,Yaw:±70°or greater)
Print Contrast Signal ≥25%
Ambient Light Dark environment, indoor natural light
Wireless communication mode Synchronization , storage
Wireless transmission distance 2.4GHz,150meters(Open distance), Bluetooth 30m ( Open distance)
Storage 16Mb(over 100,000 Product code)
Battery capacity 2200mAh
Battery charging time About 5 hours
Continuous working time ≥16hours
Symbologies

1D:Codabar,Code39,Code32,Interleaved 2 of 5(ITF25),Industrial 2 of 5,Matrix 2 of 5,Code93,Code11,Code128,Gs1-128,UPC-A,UPC-E,EAN/JAN-8,EAN/JAN-13,ISBN,ISSN,GS1 databar,GS1 databar limited,GS1 databar expanded,ISBT

2D:PDF417,Micro PDF417,QR Code,Micro QR,Data Matrix,Aztec

Company profile:

High Resolution 2.4G Bluetooth Barcode Reader

High Resolution 2.4G Bluetooth Barcode Reader

Application:

High Resolution 2.4G Bluetooth Barcode Reader

High Resolution 2.4G Bluetooth Barcode Reader

High Resolution 2.4G Bluetooth Barcode Reader

High Resolution 2.4G Bluetooth Barcode Reader

FAQ

Q: Can i make a trial or sample order before ordering?
A: Yes,sure

Q: How can i print my logo on printer? how much ?
A: Firstly,pls inform us your logo and printing position expected,then we will make sample for your confirmation shortly The cost depends on some factors.

Q: Can we have our logo or company name to be printed on the product or package?
A: Yes, printer with logo or company name is acceptable, it will be accomplished by silk printing, please contact us for more details.

Q: How about your warranty?
A: The buyer will enjoy 1 year warranty since buying from us

Q: If the scanner not working ,how can we do ?
A: pls contact and inform related sales representative with the issues you have
