Compact OEM 2D Barcode Scanner Module Durable PDF417 Barcode Engine for Easy Integration
Compact OEM 2D Barcode Scanner Module Durable PDF417 Barcode Engine for Easy Integration
Compact OEM 2D Barcode Scanner Module Durable PDF417 Barcode Engine for Easy Integration
Compact OEM 2D Barcode Scanner Module Durable PDF417 Barcode Engine for Easy Integration
Specifications
Brand Name :
Dingyu/ DY SCAN
Model Number :
DE2290
Certification :
CE, ROHS, FCC, IEC, FDA
Place of Origin :
China
MOQ :
1 Pcs
Price :
Negotiate
Payment Terms :
T/T, Paypal, Alibaba
Supply Ability :
10000pcs/month
Delivery Time :
3-7 days
Packaging Details :
188mm L * 95mm W * 40mm H
Dimension :
21.38mm L × 15.84mm W × 11.58mm H
Interface Type :
FFC 12PIN Pitch 0.5
Resolution :
640×480 CMOS
Scan angle :
Horizontal 40°× Vertical 30°
Print contrast :
≥25%
Weight :
3.4g
Description

Compact OEM 2D Barcode Scanner Module Durable PDF417 Barcode Engine for Easy Integration

Product description

The DE2390 is a high-performance 1-megapixel embedded 2D image module featuring advanced CMOS image recognition technology and an intelligent image processing system.

With its exceptional reading capabilities, it can effortlessly scan barcodes on various media, including paper, merchandise, and screens.

The compact, integrated design makes it easy to embed into a wide range of equipment.

This module is widely used in self-service machines, price checkers, lockers, and more.

Compact OEM 2D Barcode Scanner Module Durable PDF417 Barcode Engine for Easy Integration

Parameter

Weight 3.4g(without cable)
Size 21.38mm L × 15.84mm W × 11.58mm H
Interface

USB,USB-com(Need driver) ,TTL

(USB protocol:Full Speed ,USB 2.0)
Light Source Lighting: white LED(Automatically adjust brightness according to distance) Aiming: Red LED,wavelength coverage 525nm
CMOS 640×480 CMOS
CUP ARM32-bit
startup time 750ms
Resolution 1D:≥3mil,2D:≥8.7mil @PCS90%
Depth of field 3mil:55~100mm,13mil:55~350mm
Scan mode Trigger mode,Auto sense mode, Command control
prompting mode LED indicating lamp,buzzer
Reading angle Roll:±360°,Pitch:±60°or greater,Yaw:±70°or greater)
visual angle Horizontal 40°× Vertical 30°
Motion tolerance 25cm/s
Power input 3.5V~5V (DC5V is recommendation) standby current:47mA,Decoded average current:180mA
Print contrast 25%PCS
Ambient Light 70000Lux
Symbologies

1D:Codabar,Code39,Code32,Interleaved 2 of 5(ITF25),Industrial 2 of 5 Industrial 25 code,Matrix 2 of 5,Code93,Code11,Code128,Gs1-128,UPC-A,UPC-E,EAN/JAN-8,EAN/JAN-13,ISBN,ISSN,GS1 databar,GS1 databar limited,GS1 databar expanded,ISBT,MSI,Febraban(Brazil bank code)

2D:PDF417,Micro PDF417,QR Code,Micro QR,Data Matrix,Aztec
Operating temperature -20℃ to 55℃
storage temperature -20℃ to 60℃
Humidity 5% to 95%(non-condensing)
Transport vibration test 10H@125RPM

FQA:

Q1: How do you make sure the high quality barcode scanner?

DYscan: we are pofessional manufacturer and developer of barcode scanner, with rich field experience for 18 years.

Professional QC team and testing machine (Engine age test,wire bend machine,switch life test,shock resistance test).

All our barcode scanners pass CE,FCC,ROSH certifications etc.

Q2: How do you make quality control?

DYscan: we have wire bend test 1 million times, buttons are tested 1 million times, all the devices will be tested before send out.


Q3: How long is the warranty time of barcode scanner?

DYscan: 12 months

Q4: How to control the performance stable?

DYscan: We take the flow line production in the whole processing. Every product will be tested 4 times at least before delivery.

Q5: Can you provide OEM or ODM service for barcode scanner?

DYscan: We can do OEM, such as printing your own logo, color box, user manual. And we have our own technical team to support ODM service.
