Image performance system

X-ray sensor: 1 Type photo-diode array detector, 12bit

Monitor: High resolution 17inch color led display

Color quality: 24 bit real colors

Edge enhancement: object contour edge is more distinct

Super image enhancement: image detail is more distinct

High penetrate strength display: increase brightness of dark area in image to diplay object which is behind high absorption mass distinctly

Low penetrate strength display: increase brightness of image/decrease brightness of image

Image recurrence: display previous twenty images and process any one of them

Image restoration: restore image to initial status at the time of stopping conveyor

Image storing: real time store any image and process it in operation status

Multi-energy function

Multienergy color: display organic material for orange, display inorganic material for blue, and display mixture for green

High enery/low energy: switch to display tow energy type, high energy stands for metal etc, low energy stands for non metallic

Auxilitay function for drugs &explosives: help to detect such dangerous material as drugs&explosives ect

Audible&visible alarm: give sound and visible signal when confirming to condition

Alarm by sounds&light: Alarm by sound and light when confirm to condition

Network interface: It can connect to local area network and support multi-terminal check baggage at same time.

Safty ray: Transmit ray under automatic control, avoiding any baggage missing.

Image monitoring for userfriendly: The monitor use fold, rotary system, operators, adjusts the monitor position willfully according to our own need, reduce wearily.

Simple operation by mouse: Without keyboard and work table, control by mouse, save space.

Turn off a key control: Turn off the machine only need one step, revolove the key then the equipment automatic secuirty close down and no need complex steps.

Eagle-eye: It can be expediently observing enlarged area.

Estimate malfunction by self: Automatic estimate malfunction and prompt message, helpful for maintenance

1. What is the minimum order quantity?

The MOQ is 1 set.

2. What is the lead time?

3-5days after T/T payment, for other products please contact us for details.

3. What is the payment term?

The payment term is T/T ,L/C before shipment.

4: How does your company and factory do regarding quality control?

Every products will be detected after producing and approved by ISO9001 and CE certificate.
