Oilwlel A1400PT A1700PT Mud Pump Fluid End Unibody Module from China
Oilwlel A1400PT A1700PT Mud Pump Fluid End Unibody Module from China
Oilwlel A1400PT A1700PT Mud Pump Fluid End Unibody Module from China
Oilwlel A1400PT A1700PT Mud Pump Fluid End Unibody Module from China
Oilwlel A1400PT A1700PT Mud Pump Fluid End Unibody Module from China
Oilwlel A1400PT A1700PT Mud Pump Fluid End Unibody Module from China
Specifications
Brand Name :
Oilwlel
Model Number :
A1400PT A1700PT
Place of Origin :
China
MOQ :
1 set
Price :
USD 5000-10000/set
Payment Terms :
T/T
Supply Ability :
50 sets/month
Delivery Time :
35 days
Packaging Details :
case
Material :
35CrMoA
Pressure :
7500psi
Type :
L shaped
Color :
as required
Description



Gaomi Eastland Oilwell Machinery Co.,Ltd

Module

Heat-treated and internally hardened for high durability; available in various materials to meet a wide range of applications; standard one-and/or-two-piece configuration, with designs available for pressure of 5000psi(35.1Mpa), 7500psi(52.7Mpa), and 10000psi(70.3Mpa); discharge connections available on each side; suction connections on each side or front center.

● 100% interchangeable with OEM

● Premium forged alloy steel

● Made on CNC boring mills

● Strict computer controlled heat treat procedures

● Rigid inspection

Fluid End Accessories

Eastland offers a complete line of accessories for OEM fluid end modules, CNC machining

makes these accessories uniformly dimensional and interchangeable with OEM.

The perfect exterior surface reflects the superior inside quality.

Fluid end accessories include,

● Valve and cylinder head plug

● Valve and cylinder head thread ring

● Upper and lower valve guide

● Stud and nut

● Gasket, Cylinder Head Gasket, etc.

Avaliable Mud Pump ModuleTypes:

"I" shaped module, "L" shaped module, 5000 psi module,7500 psi module, Southwest type module

Avaliable Mud Pump Models:

Emsco/Bomco:F-500/F-800/F-1000/F-1300/F-1600/FB-1300/FB-1600

National:7-P-50/8-P-80/9-P-100/10-P-130/12-P-160/14-P-220

Oilwell:A-850-PT/A-1100-PT/A-1400-PT/A-1700-PT

Gardner Denver:PZ-7/PZ-8/PZ-9/PZ-10/PZ-11

Ideco: T-500/T-800/T-1000/T-1300/T-1600

LS National: 3NB-500C, 3NB1000C,3NB1300C, 3NB1600

Wirth:TPK-1000/TPK-1600/TPK-2200

Drillmec:7TS600, 9T1000, 12T1600

RussianPumps:UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L

Romania: 3PN-1000,3PN-1600, 3PN-2000

OPI:700-HDL | 1000-HDL

EWCO W-446 6 x 6
LINERS LINER GASKETS PISTONS
SIZE CERAMIC SUPREME RUBBER URETHANE SUPREME GREEN DUO FLEXLIP SUPREME
4" 07562400 05562400 07916537 012180170 015180102
4 1/4"
4 1/2" 07562450 05562450 07916537 012180197 012180196 1502054 011102928 015180145 015180144
4 3/4"
5" 07562500 05562500 07916537 012180254 012180253 1502056 011103033 015180186 015180185
5 1/4"
5 1/2" 07562550 05562550 07916537 012180338 012180337 1502058 011103132 015180228 015180227
5 3/4"
6" 07562600 05562600 07916537 012180395 012180394 1502060 011103629 015180269 015180268


VALVES, SEATS, SPRINGS & INSERTS GASKETS
ROUGHNECK SUPREME OEM URETHANE L STYLE URETHANE
N/A Valve Cover 07916826
9700099 060152949 07916830
N/A N/A Plug Seal
SEAT 080130248 061103008 HYDRA-LOK OEM MISSION L
SPRING 055413389 Complete Assembly
055403067
9705058 062400114 MODULES OEM MISSION L
N/A N/A Complete Assembly



Oilwlel A1400PT A1700PT Mud Pump Fluid End Unibody Module from ChinaOilwlel A1400PT A1700PT Mud Pump Fluid End Unibody Module from China


Oilwlel A1400PT A1700PT Mud Pump Fluid End Unibody Module from China
