Horizontal Fiber Optic Splice Closure 2 In 2 Out Underground Wall-mounting
Horizontal Fiber Optic Splice Closure 2 In 2 Out Underground Wall-mounting
Horizontal Fiber Optic Splice Closure 2 In 2 Out Underground Wall-mounting
Horizontal Fiber Optic Splice Closure 2 In 2 Out Underground Wall-mounting
Horizontal Fiber Optic Splice Closure 2 In 2 Out Underground Wall-mounting
Horizontal Fiber Optic Splice Closure 2 In 2 Out Underground Wall-mounting
Horizontal Fiber Optic Splice Closure 2 In 2 Out Underground Wall-mounting
Horizontal Fiber Optic Splice Closure 2 In 2 Out Underground Wall-mounting
Specifications
Model Number :
FOSC-H2A
Place of Origin :
Zhejiang, China
Brand Name :
DOWELL
MOQ :
1000 pieces
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
1000 PCS Per 7 Days
Delivery Time :
7- 15 Days
Capacity :
Bunchy:12-96 cores、Ribbon:72-288 cores
Diameter :
φ20mm
Number of Ports :
2 In 2 Out
Dimension :
370mm×178mm×106mm
Description

Horizontal Fiber Optic Splice Closure 2 In 2 Out Underground wall-mounting​

Horizontal type fiber closure is like a flat or cyclindrical. This type of fiber splice closure is the most commonly used one in mounted aerials or buried underground. Usually contains one or more fiber splice trays to provide space and protection for fiber optic splices. The scope of application is: aerial, underground, wall-mounting, duct-mounting, handhole-mounting. The ambient temperature ranges from -45℃ to +65℃.

Dimension And Capacity

Outside dimension (LxWxH) 370mm×178mm×106mm
Weight (excluding outside box) 1900-2300g
Number of inlet/outlet ports 2 (pieces) on each side (total 4 pieces)
Diameter of fiber cable φ20mm
Capacity of FOSC Bunchy:12-96 cores,Ribbon:72-288 cores

Necessary Tools For Installation

1 Pipe cutter 4 Band tape
2 Crossing/Paralleling screwdriver 5 Electrical cutter
3 Wrench 6 Stripper

The process of installing FOSC

Type 1. In the optical cable opening of the end of the 50mm to keep the strengthening of the reinforcement bar.

Horizontal Fiber Optic Splice Closure 2 In 2 Out Underground Wall-mounting

Type 2. Will need to be fused to disconnect the cable from the middle

Horizontal Fiber Optic Splice Closure 2 In 2 Out Underground Wall-mounting

Type3. Install and lock the cable in the cable sheath and attach the cable to the cable.​

Horizontal Fiber Optic Splice Closure 2 In 2 Out Underground Wall-mounting

Type 4. With electrical tape to the optical cable hoop protruding part of the tight.

Horizontal Fiber Optic Splice Closure 2 In 2 Out Underground Wall-mounting

Type 5. Select the outer diameter of the cable slightly larger than the sealing clip ring to cut off. Place the end part of the rubber strip in the middle of the two sealing ring and use the finger to put the glue on the cable. To maintain the natural state of the adhesive tape or a slight force, in order to make the wrapped layers of adhesive layers of clothing, no obvious gap.

Horizontal Fiber Optic Splice Closure 2 In 2 Out Underground Wall-mounting
Type 6. The cable has been installed on the sealing ring into the connection box and cable port, will continue into the additional support slot box, coiled cable stripping, stored into the connection box before the space in the tower.

Horizontal Fiber Optic Splice Closure 2 In 2 Out Underground Wall-mounting

Type 7. Cable coil stripping, stored into the connection box before the space in the tower

Horizontal Fiber Optic Splice Closure 2 In 2 Out Underground Wall-mounting

Type 8. On the first disc groove along the fiber protection groove after hot melt pipe Around. In case of need, the remaining length can be as shown in Figure ten Word direction coil.

Horizontal Fiber Optic Splice Closure 2 In 2 Out Underground Wall-mounting

Type 9. To bind the connecting plate on the connecting plate holder with a fixed strap (which is face up) with a continuous disk.

Horizontal Fiber Optic Splice Closure 2 In 2 Out Underground Wall-mounting

Type 10. Close the upper and lower cover in proper order with the box body fastening buckle.

Horizontal Fiber Optic Splice Closure 2 In 2 Out Underground Wall-mounting
