High Professional Vacuum Brazing Furnace 1350℃ Max Furnace Temperature
High Professional Vacuum Brazing Furnace 1350℃ Max Furnace Temperature
Specifications
Brand Name :
EasyFashion
Certification :
ISO9001:2008
Place of Origin :
China
MOQ :
1 set
Price :
To be discussed
Payment Terms :
T/T, Western Union
Supply Ability :
2-10 sets per year
Delivery Time :
180 working days
Packaging Details :
standard packing, wooden cases
rated supply voltage :
380v
rated loading capacity :
50
ultimate vacuum degree (Pa) :
≤6.67(empty furnace in cold status)
max.furnace temperature :
1350℃
rated power :
50kw
Description

Vacuum Brazing Furnace

I. Overview

Vacuum brazing furnace is principally adopted in Al brazing, Cu brazing and stainless-steel brazing of aerospace devices, vehicle components, electronic communicating devices, home appliances, heat exchanger and various heat radiators.

II.Technical specifications

Specification/ Model EFZK-QH-50 EFZK-QH-100 EFZK-QH-200 EFZK-QH-300 EFZK-QH-400
Rated loading capacity (kg) 50 100 200 300 400
Max. furnace temperature (°C) 1350
Temperature controlling precision (°C) ≤±5
Rated power(kW) 50 90 120 150 180
Rated supply voltage (V) 380
Rated heating voltage (V) Based on design. Furnace-front transformer is equipped.
Ultimate vacuum degree (Pa) ≤6.67 (empty furnace in cold status)
Vacuum pressure rising rate (Pa/24h) ≤50
Gas cooling pressure (Mpa) ≤0.1Mpa
Working zone size (mm) 300*300*400 300*300*500 450*400*670 450*400*850 600*600*1000
Configuration of temperature controlling system Programmable regulator of Japan SHIMADEN
Configuration of vacuum system Rotary vane pump+ Roots pump
Note: The above is standard configuration which is adjustable based on customer requirements.

III. Features

1. Single chamber, interior heating, cool wall, vertical and horizontal layout are all available with compacted structure. Customers avail from various choices to fit their specific application needs.

2. Heating chamber of this vacuum brazing furnace is fitted with temperature control deployed in several zones. Hence, outstanding heat uniformity is aggressively guaranteed.

3. Well-conceived thermal insulation shield is available in this vacuum brazing furnace, whereby promoting heat efficiency.

4. Vacuum system of this vacuum brazing furnace comes with specialized condensation filter to eliminate pollution that brazing flux vapor brings to vacuum pump.
