15 - Tube Reduction Furnace Six Heating Zones 460kw Fully Automatic Control
15 - Tube Reduction Furnace Six Heating Zones 460kw Fully Automatic Control
Specifications
Brand Name :
EasyFashion
Model Number :
460kw
Certification :
ISO9001:2008
Place of Origin :
China
MOQ :
1 set
Price :
To be discussed
Payment Terms :
T/T, Western Union
Delivery Time :
15~25 sets per year
Packaging Details :
standard packing, wooden cases
power capacity(kw) :
460kw
max.temperature :
1150
max.working temperature :
1050
heating zone number :
six zones
output T/24h :
1.6T
Description

15-Tube Reducing Furnace

Overview:

The equipment combines international and domestic practical situation on the basis of digesting and adopting overseas advanced equipment, researches and produces out multi-piping furnace for fitting the reduction of tungsten molybdenum.

Technical specifications:

Power capacity(kW) 460kW
Max. temperature (°C) 1150
Max. working temperature (°C) 1050
Heating zone number Six zones
Types of push boat Push boat pneumatically
Furnace piping dimension Φ140 or Φ128 ×10000(mm)
Hydrogen circulation amount 450m3/h~900m3/h
Output T/24h 1.6 T
Furnace weight (kg) About 35000 kg
Dimension(mm) 17100×3000×2190

Features:

1. Wide applications and fully automatic control.

2. Uniform furnace temperature, small fluctuation range, reliable control preision.

3. Output powder granularity is uniform and the distributing range is narrow.

4. Reasonable equipment structure, adopts new energy-saving type brasque.
