Steel Material Conveyor Belt Furnace High Degree Automation With Modular Structure
Steel Material Conveyor Belt Furnace High Degree Automation With Modular Structure
Specifications
Brand Name :
EasyFashion Industry
Model Number :
EF-GD-1000/70-3
Certification :
CE Certificate
Place of Origin :
China
MOQ :
1 set
Supply Ability :
10 set per year
Delivery Time :
120 days
Packaging Details :
Standard packed by wooden cases and container.
Rated furnace temperature (°C) :
900
Max. furnace temperature (°C) :
1050
Furnace temperature deviation (°C) :
±5
Production capacity (ton/year) :
1500
Width of steel belt (mm) :
1000
Material of steel belt :
SUS321 or SUS310S
Description

Electronic Iron Powder High Productivity Steel Belt Reduction Furnace

Features

1. Tremendous and high quality output

Metal powders are directly deployed uniformly on steel belt to make the best use of furnace room. Heat treatment is effectively acting on materials on the basis of fast adjustment on temperature and conveyor speed.

2. Low energy consumption

All fiber needle felt carpet comes with modular structure, thus offering excellent thermal insulation, low energy storage and minimal heat loss.

3. Durable furnace tube

Steel belt reduction furnace is fitted with pre-pressing system for furnace tube. Moreover, silicon carbide board is placed under furnace tube. The board has great rigidity, low coefficient of friction and considerable resistance to high temperature. As a result, metal tube receives balanced heating for smooth thermal expansion, and service life is 1.3 times more than similar products.

4. High degree of automation

This steel belt reduction equipment has fully automatic control on temperature and production process. Comprehensive alarm system and interlocking protection ensure everything to be favorable in a holistic approach.

5. Steel belt reduction furnace is principally used in powder metallurgy industry for processing metal powder with deoxidization in large scale, such as iron powder, copper powder, cobalt powder, molybdenum powder, tungsten powder, and for the sintering and precise reduction of metallic salts, such as cobalt oxalate and APT.

Technical specifications

Specification/ model EF-GD-1000/70-3 EF-GD-1000/70-5 EF-GD-1220/70-6 EF-GD-1220/70-10 EF-GD-1220/70-12
Rated furnace temperature (°C) 900
Max. furnace temperature (°C) 1050
Furnace temperature deviation (°C) ±5
Production capacity (ton/year) 1500 3000 5000 7500 10000
Width of steel belt (mm) 1000 1000 1220 1220 1220
Material of steel belt SUS321 or SUS310S
Material of muffle furnace tube in heating section Heat-resistance stainless steel/ silicon carbide combined with silicon nitride (based on the customer’s demands)
Quantity of heating zone 3 5 6 10 12
Heating method Heating by electricity/natural gas
Heating power (kW) 120 200 300 450 600
Steel-belt linear speed (mm/min) 30~150 50~250 80~400
Thickness of iron powder (mm) 15-50mm adjustable, usually 30mm
Length of heating furnace body (mm) 4000 7500 10000 7500×2 10000×2
Total length (mm) About 16000 About 23000 About 28000 About 38000 About 48000
Note: The above is standard configuration which is adjustable based on customer requirements.
