240L Industrial Spray Dryer , Z Type Double Wall Spray Drying Equipment
240L Industrial Spray Dryer , Z Type Double Wall Spray Drying Equipment
Specifications
Brand Name :
EasyFashion Industry
Model Number :
GN300D
Certification :
CE Certificate
Place of Origin :
China
MOQ :
1 set
Supply Ability :
10 set per year
Delivery Time :
120 days
Packaging Details :
Standard packed by wooden cases and container.
Rated voltage :
380 V 50 Hz, three-phase five-wire
Rotary speed of blending shaft (Without loading) :
10～35r/min ( Adjustable)
Max. capacity :
240L
Max. blending weight :
300 kg/run
Ultimate vacuum :
-0.08MPa
Pumping rate :
2.1 m3/min
Description

Z-type Blending Dryer

1. Overview

Z-type blending dryer integrates functions of stirring, drying, and medium recycling..

The equipment consists of electric system, vacuum pump, TCU, and alcohol recycling system..

The box of the equipment with double-walled water jacket is made of stainless steel. Specially, the inner wall is made of stainless steel with mirror surface.

There are two Z-type shafts, which are processed from two whole stainless steel forging.

2. Technical specifications

Model

 GN300D

Rated voltage

380 V 50 Hz, three-phase five-wire

Rotary speed of blending shaft (Without loading)

10～18r/min

( Adjustable)

Blending power

 7.5kW

Working frequency

10~50Hz

( Adjustable)

Power of vacuum pump

 5.5KW

Pumping rate

 2.1 m3/min

Max. capacity

 240L

Ultimate vacuum

 -0.08MPa

Max. blending weight

300 kg/run
