340 kVA vacuum heat treatment furnace  , sintering process in powder metallurgy
340 kVA vacuum heat treatment furnace  , sintering process in powder metallurgy
Specifications
Brand Name :
easyfashion
Model Number :
GN
Certification :
ISO9001:2008
Place of Origin :
china
MOQ :
1 set
Payment Terms :
T/T, Western Union
Supply Ability :
15~25 sets per year
Delivery Time :
90~160 days
Packaging Details :
standard packing, wooden cases
Product name :
Vacuum sintering and de-waxing furnace
Max. testing temperature :
1600°C
Max. working temperature :
≤1550°C
Rated voltage :
380 V 50 Hz, three-phase five-wire
name :
Vacuum Sintering Furnace
certification :
ISO9001:2008
Description

Vacuum sintering and de-waxing furnace

  • Main Description

Integrated Vacuum Degreasing and Sintering Furnace integrate the functions of de-waxing, sintering, atmosphere controlling and cooling etc.

  • Technical specifications

Model

 GN5518A GN3312A

Rated voltage

380 V 50 Hz, three-phase five-wire

Dimension of furnace

 4500×5400×3500 mm 4500×4250×3500 mm

Dimension of usable space

 500×500×1800 mm 300×300×1200mm

Max. load weight

 1500 kg 500 kg

Weight of furnace

 ≈5500 kg ≈4000 kg

Stand area

 ≈5200×6000 mm ≈4500×4000mm

Power

 340 kVA 200 kVA

Max. testing temperature

 1600°C

Max. working temperature

 ≤1550°C

Temperature control method

3 zones

Temperature uniformity

≤±7°C

(Ceramic ring)

Hc deviation

 ≤±0.3KA/M

Com deviation

 ≤±0.2%

Temperature increasing rate (without loading)

15°C/min(≤1000℃)；

10°C/min(≥1000℃)

Ultimate vacuum

≤2Pa, tested in cold and clean chamber

Vacuum Leak rate

≤2Pa/h(24 hours average), tested in cold and clean chamber

Pumping speed

(in cold and clean chamber)

≤20 min., pumping from 1.13×105Pa to 5Pa

Wax collecting rate

 ≥98﹪

Cooling speed

(without loading)

(cooling water ≤30°C)

From working temp. to 800°C, ≤ 3 h

From 800°C to opening door, ≤ 6 h

From working temp. to 800°C, ≤ 2 h

From 800°C to opening door, ≤ 5 h
