Metal Oxides Rotary Tube Furnace Uniform Structure With 1.6T Output
Metal Oxides Rotary Tube Furnace Uniform Structure With 1.6T Output
Specifications
Brand Name :
EasyFashion Industry
Model Number :
￠140
Certification :
CE Certificate
Place of Origin :
China
MOQ :
1 set
Supply Ability :
10 set per year
Delivery Time :
120 days
Packaging Details :
Standard packed by wooden cases and container.
Power capacity(kW) :
460kW
Max. temperature (°C) :
1150
Heating zone number :
Six zones
Types of push boat :
Push boat pneumatically
Furnace piping dimension :
Φ140 ×10000(mm)
Hydrogen circulation amount :
450m3/h~900m3/h
Description

High Temperature 15-tube Reducing Furnace For Various Metal Oxides Uniform Furnace

Reasonable equipment structure, adopts new energy-saving type brasque. Wide applications and fully automatic control. Uniform furnace temperature, small fluctuation range, reliable control preision. Output powder granularity is uniform and the distributing range is narrow.

The equipment combines international and domestic practical situation on the basis of digesting and adopting overseas advanced equipment, researches and produces out multi-piping furnace for fitting the reduction of tungsten molybdenum.

Technical specifications:

Output T/24h 1.6 T
Max. temperature (°C) 1150
Max. working temperature (°C) 1050
Dimension(mm) 17100×3000×2190
Types of push boat Push boat pneumatically
Furnace piping dimension Φ140 or Φ128 ×10000(mm)
Hydrogen circulation amount 450m3/h~900m3/h
Power capacity(kW) 460kW
Furnace weight (kg) About 35000 kg
Heating zone number Six zones
