Vacuum Oil Quenching Furnace Vacuum Heat Treatment Furnace with High Speed
Vacuum Oil Quenching Furnace Vacuum Heat Treatment Furnace with High Speed
Vacuum Oil Quenching Furnace Vacuum Heat Treatment Furnace with High Speed
Vacuum Oil Quenching Furnace Vacuum Heat Treatment Furnace with High Speed
Vacuum Oil Quenching Furnace Vacuum Heat Treatment Furnace with High Speed
Vacuum Oil Quenching Furnace Vacuum Heat Treatment Furnace with High Speed
Specifications
Brand Name :
EasyFashion Industry
Model Number :
EF-XKQY
Certification :
CE/CB/CQC/FCC/ISO
Place of Origin :
Hunan, China (Mainland)
MOQ :
1 set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
10 Set/Sets per Year
Delivery Time :
120~200 days
Packaging Details :
Standard packing, wooden cases
Voltage :
380V
After-sales Service Provided :
Engineers available to service machinery overseas
Warranty :
1 year
Max. temperature :
1350℃
Dimension(L*W*H) :
Various
Heating Elements :
Graphite And Molybdenum
Description

Vacuum Oil Quenching Furnace

I. Overview

It is mainly applied to quenching heat treatment of high-speed steel, die steel, titanium alloy, etc.. Various technology choices and processing application range are provided with full-automatic programmable controlling.

Vacuum Oil Quenching Furnace Vacuum Heat Treatment Furnace with High SpeedVacuum Oil Quenching Furnace Vacuum Heat Treatment Furnace with High Speed

II. Technical specifications

Model EF-XKQY-50 EF-XKQY-100 EF-XKQY-150
Effective heating zone(mm) 550×380×250 1000×600×450 1500×750×600
Loading capacity(kg/batch) 100 300 120
Heating power(kW) 70 100 120
Furnace temperature homogeneity(℃) ±5
Ultimate vacuum degree 2*10-1 / 6.7*10-3
Pressure rising rate(Pa/h) ≤0.67
Gas cooling pressure(bar) ≤2
Max. temperature(℃) 1350
Heating elements Graphite and molybdenum

III. Features

1. With compacted double chambers structure, vacuum oil quenching furnace is integrated with optimal layout for space efficiency.

2. Oil tank has large capacity. Inside the tank, there are nozzles in various directions. As a result, there will be intense convection and turbulence during oil spraying, whereby catering to quench for large workpieces.

3. Simple operation and flexible input ensure stable performance. Manual and automatic operation can be switched readily. Moreover, alarms will be triggered automatically on failures of the vacuum oil quench furnace.

4. This vacuum oil quenching furnace is fitted with high efficiency external oil cooling circulation system for quench.

5. Furnace tank of this vacuum quench furnace is heated as a whole unit. Internal charging trays are in stacking structure. Feeding speed is frequency regulated in slow-fast-slow mode, thus ensuring stable feeding and reduced time.

6. Vacuum degree and air cooling pressure are allowed to be adjusted to fit specific materials.

7. Unique gas cooling system comes with built-in air channel for maximized cooling efficiency.
