ADSS-AT-24B1-300 All Dielectric Self-Supporting Fiber Aerial Optical cable
ADSS-AT-24B1-300 All Dielectric Self-Supporting Fiber Aerial Optical cable
Specifications
Place of Origin :
Shenzhen,China
Brand Name :
GT-Link
Certification :
ISO,CE,RoHS,GGS
Model Number :
GT-ADSS
Installation :
Self-supporting
Strength Member :
FRP and Aramid Yarns
Sheath Material :
PE,LSZH,PVC,TPU
Fiber Number :
2~288
Package :
2KM/3KM
Operating temperature :
-40~+60°C
OEM :
Available
Model Type :
All Dielectric Aerial Cable
Loose Tube Material :
PBT
Fiber Type :
single mode or multi mode
Description

Description: ADSS-AT-24B1-300 All Dielectric Self-Supporting Fiber Aerial Optical cable

1.ADSS-AT-24B1-300 All Dielectric Self-Supporting Fiber Aerial Optical cable
2.4.Fiber:G652,24 core,OEM
3.FRP and Aramid Yarns

ADSS is usually used for the power companies data transmission communications, remote online monitoring. This optical fiber cable installed in high-voltage transmission line, this way the most suitable for installation in existing lines, and the lowest cost. Cable is completely non-metallic structure of the certer is to strengthen pieces of FRP(fiberglass reinforced plastic).

Application

l 1.Laying method: Aerial

l 2.Mainly applied in electric power system to provide a convenient way to establish communication networks. It is suitable for aerial installation when a communication line has to span a river, a valley, a thunder area and other fields with special requirements.

Characteristics

l 1.Large span lengths and the largest span is over 1700m.

l 2.Non-metallic material, with high insulating property performances as well as lightningproof

l 3.Special Anti-Track outer sheath (optional) protection, strong anti-electro-corrosion ability.

l 4.The aramid yarn ensures the cable’s tensile resistance, and also have good bulletproof performances.

l 5.Light weight with small diameter, reducing the load caused by ice and wind as well as the load on the towers and backprops.

l 6.Can be installed without shutting off the power.

Technical Specification

Cable type

ADSS-AT-24B(5.0KN)

Maximum span(m)

50

Maximum field voltage(kV)

25

Fibre type

ITU G.652D, Standard for SM Optical Fibres with 6 colour: blue, orange, green,brown, gray, white

Loose tube

PBT Loose Tube with 6 fibres in each tube and 4 colour : blue, orange, green,brown

Ref. Outer Diameter (mm)

12.1±0.1

Ref. Weight (kg/km)

130±5

Modulus of elasticity(kN/mm2)

6.24

Heat expansion coefficient (10-6/0C)

10.61

Break strength (kN) RTS

5.0

Max. allowable working tension (kN) MATS

2.01

Red.daily max.working tension (kN) MOTS

1.25

Minimum bend radius (mm)

Static

151

Dynamic

303

Attenuation coefficient

at 1310nm

≤0.36dB/km

at 1550nm

≤0.22dB/km

Temperature range

-40~+60

* We can develop & design cable according to Customer's specs requirement

Standard Reference
IEEE P1222, ITU-T G.652, TU-T G.655, IEC 60794-1, DL/T 788-2001, YD/T 980-2002

Package:

ADSS-AT-24B1-300 All Dielectric Self-Supporting Fiber Aerial Optical cable
