GYXTW central tube 2~12core single armored outdoor fiber optic cable
GYXTW central tube 2~12core single armored outdoor fiber optic cable
Specifications
Place of Origin :
Shenzhen,China
Brand Name :
GT-Link
Certification :
ISO,CE,RoHS,GGS
Model Number :
GT-GYXTW
Installation :
Aerial,Duct
Central Strength Member :
Steel Wire
Strength Member :
Steel Tape
Sheath Material :
PE,LSZH,PVC,TPU
Fiber Number :
2~288
Package :
2KM/3KM
Operating temperature :
-40~+60°C
OEM :
Available
Model Type :
Central Loose Tube
Loose Tube Material :
PBT
Description

Description: GYXTW central tube 2~12core single armored outdoor fiber optic cable

Description:

  • 1.fiber : single mode or muti mode
  • 2.tube: filled with jelly and fiber
  • 3. with water blocking tape
  • 4. steel tape armored
  • 5. two steel wires as strength member
  • 6.MDPE or HDPE outer sheath

Application:

  • Long-distance communication
  • local trunk line
  • CATV & computer networks system

Technical Features:

  • High tensile strength of stranded wires meet the requirement of self-supporting and reduce the installation cost.
  • Good mechanical and temperature performance
  • High strength loose tube that is hydrolysis resistant
  • Special tube filling compound ensure a critical protection of fiber
  • The following measures are taken to ensure the cable watertight
  • Steel wires used as the strength member
  • Loose tube filling compound
  • 100% cable core filling
  • PSP enhancing moisture-proof

Technical parameters

1.Fiber Color Arrange

Fiber No

1

2

3

4

5

6

7

8

9

10

11

12

Color

Blue

Orange

Green

Brown

Slate

White

Red

Black

Yellow

Purples

Pink

Aqua

2.Technical parameters

Total number of fiber cores

2-12

Outer diameter (mm)

8.0~

Cable Max unit weight (kg/km)

70~

Allowable pull force (N)

long-term

600

short-term

1500

Allowable crush strength (N/100mm)

long-term

300

short-term

1000

Min bending radius (mm)

static

10 times of cable external diameter

dynamic

20 times of cable external diameter

Application of temperature

-40°C-60°C

3.Product properties

  • Low dispersion and attenuation.
  • Proper design, precise control for fiber excess length and distinct stranding process render the cable excellent mechanical and enviromental properties.
  • Compact structure and lightness, flexible and good bend-resistant performance.
  • Good mechanical and temperature performance

4.Laying mode: aerial ,duct

5.operating temperature:-40°C-60°C

6.Application: Apply to long-distance communication and communication between

Packaging & Delivery

Packaging Detail:

packed on drums suitable for long distance shipment, the drum is fumigated or non fumigated.

Delivery Detail:

according to the ordered quantity, On customer's request, 1000m~5000m rolller
