Self Support FTTH Indoor Drop Fiber Cable with Steel Wires Messenger
Self Support FTTH Indoor Drop Fiber Cable with Steel Wires Messenger
Specifications
Place of Origin :
Shenzhen,China
Brand Name :
GT-Link
Certification :
ISO,CE,RoHS,GGS
Model Number :
Coring,YOFC, J-fiber
Installation :
Indoor Drop Cable
Sheath Material :
PVC,LSZH
Fiber Number :
1/2/4
Fiber Type :
G652D,G657A
Certifications :
ISO9001,ROHS
Color Sheath :
white,black or as customized
Armored(1) :
Steel Wire or FRP or KFRP
Packing :
Wood Drum,Carton Box
Packing Length :
1-2KM
Cable Model :
Drop Self Supporting Type
Description

Description: Self Support FTTH Indoor Drop Fiber Cable with Steel Wires Messenger

1.Self Support FTTH Indoor Drop Fiber Cable
2.Cores are in centre
3.FRP/KFRP/Steel wire strength
4.Steel Wires Messenger,Fig8

The optical fiber unit is positioned in the centre. Two parallel Fiber Reinforced Plastics (FRP) are placed at the two sides. A steel wire as the additional strength member is also applied. Then, the cable is completed with a black or color LSZH sheath.

Characteristics

  • Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property
  • Two parallel FRP strength members ensure good performance of crush resistance to protect the fiber
  • Single steel wire as the additional strength member ensures good performance of tensile strength
  • Simple structure, light weight and high practicability
  • Novel flute design, easily strip and splice, simplify the installation and maintenance
  • Low smoke, zero halogen and flame retardant sheath

* special curved optical fiber, providing greater bandwidth and enhanced network transmission characteristics;
* two parallel fiber optic cable, FRP has a good compression performance, can protect the fiber;
* Add the single steel wire to strengthen , so that cable has a good tensile properties;
* cable structure is simple, light weight, strong practical
* unique groove design, easy peeling, convenience for connect, and simplify installation and maintenance;
* LSNHP fire-retardant jackets, environmental protection and safety.

Descriptions: The struture of indoor optical FTTH cable :In the centre is the optical communication unit,with the parallel non-metical enhanced FRP of the two side and amessenger outside.The sheath materiar is LSZH or PVC.

Type

Cores

Cable diameter(mm)

Short stretch(N)

Long-term tensile(N)

Short squash(N/100cm)

Long-term squash(N/100cm)

Static

Dynamic

Weight (Kg/Km)

FTTH-1Xn

1

2.0*5.0

60

120

300

1000

15D

30D

20

FTTH-2Xn

2

2.0*5.0

60

120

300

1000

15D

30D

20

*The cable model specifications, size and strength can made the suitalbe adjust according to the customer's requirements.
