SC-SC Single Mode Simplex Optical Fiber Jumper
SC-SC Single Mode Simplex Optical Fiber Jumper
SC-SC Single Mode Simplex Optical Fiber Jumper
SC-SC Single Mode Simplex Optical Fiber Jumper
Specifications
Place of Origin :
Shenzhen,China
Brand Name :
GT-Link
Certification :
ISO,CE,RoHS,GGS
Model Number :
GT-SC,SM,SX
Connector Type :
SC
Cable Dia. :
0.9/2.0/3.0mm
Insertion Loss :
≤0.3db
Return Loss :
≥45db
Length :
3M or as customized
Cable :
Simplex,Duplex
Type :
FC,SC,ST,LC,MU,MRTJ
Color :
Yellow,Orange or customized
Polishing :
PC,UPC,APC
Connector Color :
Blue or customized
Description

Descriptioin:SC-SC Single Mode Simplex Optical Fiber Jumper

Both single-mode and multimode versions SC fiber patch cord come with a zirconia ceramic ferrule with pre-polished PC profile and convex spherical end. These end face types allow for faster polishing, and low back reflection and optical loss, while ensuring maximum repeatability.

1.SC-SC Single Mode Simplex Optical Fiber Jumper
2.High return loss,Low insertion loss
3.cable diameter:3.0mm,2.0mm,0.9mm
Fiber Jumpers Features:
  • Telcordia’s GR-326-Core, IEC Standard
  • Green Production, RoHS Standard
  • Excellent Polished and 100% tested.
  • High stability various environments
  • Customize order available

Fiber Jumpers Applications:

  1. Telecommunication Networks
  2. Gigabit Ethernet , GPON , EPON
  3. Computer networks
  4. CATV networks
  5. FTTx Termination

Fiber Jumpers Technical Standard:

Mode SM MM
Polish UPC APC PC
Insertion Loss ≤0.2dB ≤0.3dB ≤0.2dB
Return Loss ≥55dB ≥65dB ≥35dB
Interchangeability ≤0.2dB
Salt Spray ≤0.1dB

Repeatability

 ≤0.1dB (1000 times)

Vibration

 ≤0.2dB (550Hz 1.5mm)

Temperature

 ≤0.2dB (-40+85 sustain 100 hours)

Humidity

 ≤0.2dB (+25+65 93 R.H.100 hours)

Apex Offset

 0μm ~ 50μm

Radius of Curvature

 7mm ~ 25mm

Contact and Return Service:
1)We will reply your email and fax within 24 hours
2)You can call us at any time if there is any question on our production
3)To return product, you may contact us before.
4)To serve you better, please specify the reasons of the return.
