Detailed Product Description:
AV6471 is an optical fiber splicing device with a brand new design. With powerful functions and super low splicing loss,
it is highly competent for construction of trunk lines and FTTx. Lightweight and compact, it is easy to use even in
confined space. The novel fiber imaging system makes the image clearer. The real-time embeded Operating System provides
a friendly man-machine interface and abundant functions. The built-in large capacity Li-Ion battery can support long-time field work. The real-time compensation system for temperature, humidity and air pressure has greatly enhanced the device against unfavorable environment changes and thus guarantees its consistency of low loss splicing in various environments.

Several Key Features:
ο New fully-digitalized design;
ο Small in size, lightweight: only 2.8kg with battery;
ο Takes only 8 seconds for splicing,25 seconds for pyrocondensation;
ο Can set automatic start of splicing or of pyrocondensation upon close of the cover;
ο Simultaneous display of X/Y axis; zoom in up to 304 times original size;
ο Real time discharging for adjustment; no need for further adjustment;
ο Electrode has a long life; discharging times up to 4000;
ο With USB and VGA ports;
ο 5.7 inch digital high resolution LCD;
ο Precise real-time display of remaining battery capacity;
ο Built-in high capacity battery, which enables up to 220 times of splicing and heating;

Technical Parameters:

Warm Notice to Users :

Please fax the “after service form”to our service department within 7 days after buying the products, so that we can verify your product.We will provide you the perfect after -sales service when receiving the form.The following situations are not within the scope of warranty service :

1. due to personal or non- maintenance units of the company agent disassemble , repair or damage caused by the failure ;

2. due to force majeure and human factors led to the failure or damage ;

3. the use of an external power supply voltage is not normal due to malfunction or damage ;

4. Consumable parts ( eg : Electrical welding electrode rod, cutter blades , OTDR optical connectors and adapters and a variety of battery )
