DZQ-700L/S External food vacuum packaging machine
DZQ-700L/S External food vacuum packaging machine
Specifications
Place of Origin :
China
Brand Name :
China Coal
Certification :
ISO,MA,CE,SGS,TUB,BV
Model Number :
DZQ-700L/S External food vacuum packaging machine
Description

DZQ-700L/S External food vacuum packaging machine

vacuum packaging machine, vacuum packing machine, packaging machinery
ChinaCoal02
www.chinacoalintl.com
www.leadingpacking.com

zhongmeixx12@gmail.com

DZQ-700L/S External food vacuum packaging machine

DZQ-700L/S External food vacuum packaging machine Introduction


External multi-function modified atmosphere vacuum packaging machine is a basic external vacuum packaging machine, plus could be fixed gas flush system for inertgas filling or mixed gas filling in the packaging according to customers’ actual requirements. We will supply powder filter according to power’s mesh number if the packing item is powder at customers’ option. Generally heat sealing comes with single sealer, double sealers heat sealing can be chose according to customers’ bags different thickness at customers’ option.


DZQ-700L/S External food vacuum packaging machine Features:


1.Control system: OMRON programmable PLC, text display.
2.Pneumatic system::Taiwan Air TAK pneumatic component.
3.External vacuum suction structure: Two cylinders, two suction nozzles.
4.Lift-down conveyor, easy in operation.
5. Heavy moving wheel (with brake): The heavy moving wheel with high bearing capability, which makes customer moving easily.


DZQ-700L/S External food vacuum packaging machine Technical Parameter:

DZQ-700L/S External food vacuum packaging machine

Model(vacuum packaging machine)

DZQ-700L/S (stainless steel)

Machine Dimension(mm)

730*830*1800

Sealer Form

Double Heat

Sealer Dimension(mm)

700*10*2

Sealer Power Consumption(kw)

1

Pump Capacity(m3/h)

20

Pump Power Consumption(kw)

1.1

Voltage(v)

110/220/240

Hertz(Hz)

50/60

Production Cycle(times/min)

2-3

Sealer Adjustment Range(mm)

1300-475

Conveyor Width (mm)

230

Conveyor Length (mm)

720

Conveyor Loading(kg)

50

N.W.(kg)

160

G.W.(kg)

230

Shipping Dimension(mm)

1900*920*1120
