250KW Cummins power generation emergency power supply 313kva
250KW Cummins power generation emergency power supply 313kva
Specifications
Place of Origin :
China
Brand Name :
GTL
Certification :
CE, ISO9001, ISO14001
Model Number :
CCW-313T5
Controller :
Deepsea, Woodward, DEIF,ComAp, Smartgen
Speed :
1500rpm
Output Type :
AC Three Phase
Rated power :
313kva/250kw
Rated Voltage :
400V
Rated current :
452A
Description

MTAA11-G3 Cummins power generation emergency power supply 313kva

* Low fuel consumption Cummins diesel engine generator set

* Quality Generator tank: 8 hours or 12 hour or optional

* Low maintenance generator set, durable generators

* Diesel Gensets Standard chargers: Float battery charger and battery charger

* Generator diesel warranty: World warranty service

* Primary power supply generator, emergency power generator or rental generator

* Electricity equipment of mobile power station

Optional Supply

* Weatherproof/Soundproof enclosure

* Mobile trailer

* Remote radiator cooling

* Engine/alternator heaters

* Auto start/Auto mains failure(AMF) / ATS control panel, circuit breaker

* Auto load sharing & synchronizing panel

Generator set information

Diesel Genset Features
MODEL CCW-313T5
Stand-by power@50Hz 275KW/344KVA
Prime power@50Hz 250KW/313KVA

Generator Ratings
Voltage HZ phase P.F Prime Amps ESP(KW) PRP (KW)
400 50 3 0.8 453 275.0 250

Engine Data

Manufacture 　 Cummins
Model 　 MTAA11-G3
Number of Cylinders 　 6
Borexstroke mm 125x147
Rated RPM Rpm 1500
Base Output Power KW 282
Displacement L 10.8
Compression ratio 　 15.1:1
Air intake way 　 Turbo-charged & charge air
Governor method 　 Electrical

Low fuel consumption generator

Standby power L/h 70
100% prime power L/h 61.3
75% prime power L/h 44.9
50% prime power L/h 27.6

Alternator Data

* Famour alternator Brand: Stamford, Leroy Somer, Marathon or MeccAlte

* 4-pole, brushless, self exciting, self regulating

* Drip proof, IP23 protection, class H insulation

* Industrial standard, single bearing type

* Self ventilated, screen protected

* oltage regulation ±1% at any fixed load

Genset dimension

Open generator (mm): 3000*1380*1850

Weight (kg): 2900

Silent generator (mm): 3800*1380*2150

Weight (kg): 4200

250KW Cummins power generation emergency power supply 313kva
