led ceiling panel light /LED panel light quality lamps supply
led ceiling panel light /LED panel light quality lamps supply
Specifications
Place of Origin :
China
Brand Name :
Sourcechip
Model Number :
SC-PLC040S01
Certification :
CE, FCC, RoHS, UL
Contact E-mail :
sales008@sourcechip.com
website 1 :
http://www.sc-ledlights.com/
website 2 :
http://www.sc-leddownlights.com/
Description

led ceiling panel light /LED panel light quality lamps supply
China Dongguan Sourcechip Opto-electrical Tech Co.,Ltd. is a production, development and sales of LED-based lighting manufacturer. We produce every one LED lamps have strict production process and testing procedures. The led ceiling panel light is one of our main products. Its electrical properties are as follows. If you would like more details about the led ceiling panel light, please contact us by e-mail.

Dongguan Sourcechip Opto-electrical Tech Co.,Ltd. xnyuantian01

Sourcechip led ceiling panel light Contact E-mail:
Sourcechip led ceiling panel light website 1:
Sourcechip led ceiling panel light website 2:
Sourcechip led ceiling panel light Tel: +86-769-81608082
Sourcechip led ceiling panel light Fax: +86-769-81608083
Sourcechip led ceiling panel light Address: No.2 Min Yi Road, Wusha Community, Chang'an Town, Dongguan, Guangdong, China

LED PanelLights Specification

led ceiling panel light /LED panel light quality lamps supplyled ceiling panel light /LED panel light quality lamps supply

LED Model No.

SC-PLC040S01-30

SC-PLC040S01-40SC-PLC040S01-60

Rated power

33W

Consume power

40±3W

Input Voltage

AC 100-240V

Output Voltage

32-42V

Input current

860mA±5%

Efficiency

≥85%

Cutout:

/

P.F

≥0.90

Light Source CRI

Warm white

Natural white

Pure white

3000±200k

4000±300k

6000±300k

Light Source Luminous flux(lm)

≥20LM

≥21LM

≥22LM

Lighting CCT

3000±300k

4000±300k

6000±500k

Lighting LM

2900±200LM

3100±200LM

3200±200LM

Lighting View Angle

120°

Lighting CRI

≥70/≥80

Key point temperature
(during aging test)

LED Welding foot

Lamp shell

≤75°C

≤70°C

Working Temp.

-10°C~40°C / R.H.≤85%

Storage Temp.

-30~65°C

Life span

25,000 HR

IP Rate

IP20

led ceiling panel light /LED panel light quality lamps supply

led ceiling panel light /LED panel light quality lamps supply

led ceiling panel light /LED panel light quality lamps supply

Processes of Packaging
led ceiling panel light /LED panel light quality lamps supply
Application of LED Panel Light

led ceiling panel light /LED panel light quality lamps supply

led ceiling panel light /LED panel light quality lamps supply

led ceiling panel light /LED panel light quality lamps supply

Related types of LED Panel Light
led ceiling panel light /LED panel light quality lamps supply
Service and Business Terms of LED Panel Light
  1. You inquiry will be replied in 12 hours.
  2. All your inquiries will be answered in fluent English by well-trained & professional staffs.
  3. We supply OEM & ODM service for our client, natural packing and customer's packing style available without extra cost.
  4. Many optional payment terms: L/C, T/T, Western Union, Paypal, Escrow etc, guaranty customer receive high quality products.
  5. Many Optional delivery / shipping methods: by ship, by air plane, by commercial express, specific line transportation, by post, etc, guaranty the goods reach customer on time with less freight cost.

led ceiling panel light /LED panel light quality lamps supply

Certification
certification
