FAG HS7009-C-T-P4S-UL main spindle bearing 45x75x16mm,P4 Grade,steel ball,in stock
FAG HS7009-C-T-P4S-UL main spindle bearing 45x75x16mm,P4 Grade,steel ball,in stock
FAG HS7009-C-T-P4S-UL main spindle bearing 45x75x16mm,P4 Grade,steel ball,in stock
FAG HS7009-C-T-P4S-UL main spindle bearing 45x75x16mm,P4 Grade,steel ball,in stock
Specifications
Place of Origin :
Germany
Brand Name :
FAG
Model Number :
HS7009-C-T-P4S-UL
Certification :
ORIGINAL
Description

FAG bearings HS7009-C-T-P4S-UL

adjusted, in pairs or sets, contact angle α = 15°, restricted tolerances, steel ball

d: 45mm D: 75mm B: 16mm

Type:

HS

Bearing with small balls steel balls

Dimension series:

70

Medium series

Dimension（dxDxh）

45x75x16mm

Contact angle:

C

C =15° E = 25°

Cages:

T

Plastic fiber cage, outer ring guided

Precision:

P4S

P4S FAG standard, reference to DIN620, higher than P4

Bearing arrangement:

U

single bearing, universal assemble

Preload:

L

light preload

HS7009-C-T-P4S-UL High Precision Ball Bearing HS7009-C-T-P4S-UL Machine tool main spindle bearing

HS7009-C-T-P4S-UL FAG High Speed Angular Spindle Bearing, Ball Bearing is Super precision Angular with 15 degrees contact angle and Phonetic cage, bearing is P4 quality and made in Germany

Item: HS7009.C.T.P4S.UL FAG Ball Bearing，FAG machine tool main spindle bearing

Type: FAG Angular Spindle Ball Bearing

ball: steel ball

Quality: P4 Grade

Dimensions: 45mm x75mm x16mm /Metric

ID (inner diameter)/Bore: 45mm

OD (outer diameter): 75mm

Width/Height/thickness: 16mm

Size:45 x 75 x 16 mm

Quantity: One Bearing

Dynamic load rating Cr:12900 N

Static load rating Cor: 12200 N

Limiting Speed:

Grease Lubrication: 24000 RPM

Oil Lubrication: 38000 RPM

DU :Duplex set, universal bearings

TU:Triplex set,universal bearing

QY:Quadruplex set,universal bearing

PU:Quintuplex set,universal bearing

The delivery time: in stock, within one day after getting the order

Package:standard carton or standard wooden case

Shipping term:TNT,FEDEX,DHL Express or your required.

FAG HS7009-C-T-P4S-UL main spindle bearing 45x75x16mm,P4 Grade,steel ball,in stock
