FAG HSS71924-C-T-P4S-ULmachine tool main spindle bearing Dimension:120x165x22 mm,steel ball,sealed
FAG HSS71924-C-T-P4S-ULmachine tool main spindle bearing Dimension:120x165x22 mm,steel ball,sealed
FAG HSS71924-C-T-P4S-ULmachine tool main spindle bearing Dimension:120x165x22 mm,steel ball,sealed
FAG HSS71924-C-T-P4S-ULmachine tool main spindle bearing Dimension:120x165x22 mm,steel ball,sealed
Specifications
Place of Origin :
Germany
Brand Name :
FAG
Model Number :
HSS71924-C-T-P4S-UL
Certification :
ORIGINAL
Description


FAG bearings HSS71924.C.T.P4S.UL

d: 120mm D: 165mm B: 22mm

Type:

HSS

Bearing with small balls Steel balls sealed

Dimension series:

719

Light series

Dimension（dxDxh）

120x165x22mm

Contact angle:

C

C =15° E = 25°

Cages:

T

Plastic fiber cage, outer ring guided

Precision:

P4S

P4S FAG standard, reference to DIN620, higher than P4

Bearing arrangement:

U

single bearing, universal assemble

Preload:

L

light preload

HSS71924.C.T.P4S.UL High Precision Ball Bearing HSS71924.C.T.P4S.UL Machine tool main spindle bearing

HSS71924CTP4SUL FAG High Speed Angular Spindle Bearing, Ball Bearing is Super precision Angular with 15 degrees contact angle and Phonetic cage, bearing is P4 quality and made in Germany

Item: HSS71924-C-T-P4S-UL FAG Ball Bearing，FAG machine tool main spindle bearing

Type: FAG Angular Spindle Ball Bearing

ball: steel ball

Quality: P4 Grade

Dimensions: 120mm x165mm x22mm /Metric

ID (inner diameter)/Bore: 120mm

OD (outer diameter): 165mm

Width/Height/thickness: 22mm

Size:120 x 165 x 22mm

Quantity: One Bearing

Dynamic load rating Cr: 35500 N

Static load rating Cor: 32000 N

Limiting Speed:

Grease Lubrication: 11000 RPM

Oil Lubrication: 0 RPM

The delivery time: in stock, within one day after getting the order

Package:standard carton or standard wooden case

Shipping term:TNT,FEDEX,DHL Express or your required。

FAG HSS71924-C-T-P4S-ULmachine tool main spindle bearing Dimension:120x165x22 mm,steel ball,sealed
