Description

P8 Outdoor P8 LED Display for advertising , SMD Outdoor P8 LED Display Waterproof IP65,ARISELED,

Arise Technology Co., Ltd. One-stop LED display manufacturere

Website: www.ariseled.com

Skype: ariseled

Email: info@ariseled.com

http://i.youku.com/ariseled

P8 Outdoor P8 LED Display for advertising , SMD Outdoor P8 LED Display Waterproof IP65,ARI

FOB Price:US $1 - 1,500 / Square Meter

Min.Order Quantity:1 Square Meter/Square Meters

Supply Ability:6000 Square Meter/Square Meters per Month

Port: Shenzhen

Payment Terms:T/T

Packaging & Delivery

Packaging Detail: Ply Wooden case or Flight case

Delivery Detail: 15 to 25 days upon confirmation and deposit

Specifications

RGB Outdoor P8 LED display

-High brightness, weather ability

-Waterproof IP65

-Content: video, picture text

Features

1. High brightness. Use SMD Lamp, keeps the display content visible even if facing the strong sunshine directly.

2. With Anti-UV ray mask, the color of the mask would never change even if under exposure of UV ray.

3. Waterproof design, completely outdoor installation.

4. Easy for assembling, with sensor to adjust the brightness and show temperature.

5. High color uniformity and clear image can bring you a vivid audio visual effect.

6. Both front and rear access are available. Easy for maintenance.

7. Good LED Chips, with large viewing angle, low power consumption and good color uniformity.

8. Good quality raw material, accurate technique and careful inspection insures the high quality of led display.

9. Different shape and size can be made according to your requirement.

10. Widely used for building, shopping mall, cinema, station, stadium, plaza, street etc.

Outdoor P8 LED Display Parameters

Model

FO-8S

Parameters

Speci.

Pixel Pitch

8mm

Pixel Composition

1R1G1B

LED Type

3-in-1 SMD3535

Display brightness

7200cd/m² (adjustable)

Color Temperature

2500K to 10000K

Viewing Angle

H: 160°; V:160°

Pixel Density

15625 pixels/m²

Minimum Viewing Distance

≥8 M

Module Size

256mm×128mm.

Cabinet Size

W1024mm×H768mm×D180mm

Cabinet Weight

40 kg/cabinet

Cabinet Size

0.7864 m²

Cabinet Material

Iron

Cabinet Aspect Ratio

1024:768

Cabinet Resolution

128×96 pixels

Grey Scale

16bit(high refresh),14bit(common refresh)

Driving Mode

1/4 scan, constant current

Processing Depth

65536 scales

Colors

281.4 trillion

LED wave length

R: 620~630nm G: 520~535nm B: 465~475nm

Brightness Control

Manual/Automatic

Display contrast

5000:01:00

Frame Rate

50/60 Hz

Refresh Rate

3200 Hz(high refresh) ,1000 Hz(common refresh)

Input Voltage

110~220VAC±15%

Input Power Frequency

50~60 Hz

Max. Power Consumption

670W/cabinet

Ave. Power Consumption

200W/cabinet

Life Span

≥100,000 hours

Input Signal

RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc

Communication Collection

CAT5 Cable: ≤140m;

Multi-mode fiber ≤ 500m; Single mode fiber ≤ 20km )

Installation Method

Hanging /wall mounted/other customized installation methods.

Protection Scale

IP65

Operation Humidity

0℃~+45℃/10~90%RH

Storage Humidity

-10℃~+55℃/10~90%RH

Arise Technology Co., Ltd. is a high-tech company dedicated in providing professional LED displays and comprehensive optoelectronic solutions.


Arise Technology owns strong execution, brilliant development strategies and programs, sustainable creation based on market demand. We spare no effort to provide customers with market-oriented innovative products with good reliability, suitable solutions and all-round service. Our main products includes indoor and outdoor full color fixed installation LED display, indoor and outdoor rental LED displays, LED Mesh/LED curtain displays, LED advertising player displays, floor LED displays, stadium/perimeter LED displays, creative LED displays, mobile LED displays, flexible LED displays, transparent LED displays, high-resolution full color LED display, customized LED displays, and the whole display system and equipment. We are ready to providing LED display solutions for oversea and domestic advertisement media, building advertising and lighting, municipal administration, hospital, hotel, bank, traffic, sports, entertainment, show, exhibition, etc.Aisre LED displays are approved by CE, RoHS and FCC certifications.

We Arise Technology regard integrity in company staff, customers and suppliers as the enterprise foundations, market demands as the guide. We guarantee quality with profession and dedication and use enterprise culture to fill our brand. We keep striving, forging ahead, creating to provide customer with strong and unremitting support and backup.

We Arise Technology also have more LED displays for your projects:

•Outdoor fix installation LED displays: P4/P4.8/P5/ P6/ P6.67/ P8/ P10 (DIP)/ P10 (SMD)/ P10.4/ P12/ P16/ P20/ P25/ P31.25/ P40/ P50;

•Indoor fix installation LED displays: P1.6/ P1.667/ P1.8/ P1.875/ P1.9/ P2/ P2.5/ P3/ P3.9/ P4/ P4.8/ P5/ P6/ P6.67/ P7.62/ P8/ P10

•Outdoor Rental LED displays: P3.9/ P4.8/ P5/ P6/ P6.25/ P6.67/ P6.94/ P7.8/ P8/ P8.9/ P10

•Indoor Rental LED displays: P2/ P2.5/ P3/ P3.125/ P3.75/ P3.91/ P4/ P4.81/ P5/ P6/ P6.25/ P6.4/ P7.62/ P8/ P10

•Perimeter LED Displays: P6/ P8/ P10/ P12/ P12.5/ P16

•LED Advertising Player/Kiosk LED displays: P2.5/ P3/ P4/ P5/ P5.3/ P6

•Stair LED displays: P6/ P6.67/ P7.62/ P10/ P16/ P18/ P20

•Transparent LED display: p3.9/p7.81/p8/p10

•Led Street Screen: p4/p5/p6/p8

•LED Floor Tiles: P6.25/ P8.9/ P10.4

•LED ball: P3/ P4/ P5/ P6/ P7.62/ P8/ P10

•Led Stage Screen-DJ screen: P3/ P4 /P5/ P6

•Taxi LED banner signs: P4/ P5/ P6

•Bus LED banner signs: P5/ P6/ P7.62

•More customized LED displays.

P8 Outdoor P8 LED Display for advertising , SMD Outdoor P8 LED Display Waterproof IP65,ARI

We will be your best partner by providing you professional LED display products and service and support from China production base!! Should any LED display projects, please just feel free to contact!
