Specifications
Place of Origin :
CHINA
Brand Name :
ARISELED
Certification :
CE\CCC\ISO\UL\ROHS\FCC
Model Number :
P1.8mm Indoor LED video displays from high definition P1.2/P1.5/P1.8/P1.9 and P2.5/ P3.1/ to P3.84/
Description

P1.8mm Indoor LED video displays from high definition P1.2/P1.5/P1.8/P1.9 and P2.5/ P3.1/ to P3.84/ P5/ P5.33/ P6/ P6.94/ P7.8/P10

Arise Technology Co., Ltd

Web:http://www.ariseled.com

QQ:1327078259 Skype:ariseled

http://i.youku.com/ariseled

P1.8mm Indoor LED video displays from high definition P1.2/P1.5/P1.8/P1.9 and P2.5/ P3.1/

odule parameters

Pixel pitch

1.8mm

Pixel density

308642dots/m2

LED shape

SMD 0404

LED configuration

1R1G1B

Module Resolution

104*52

Module Size

188*95

Drive mode

1/32

Cabinet parameters

Cabinet Resolution

312*312

Cabinet Size

564*564

Module Quantity

18pcs

Cabinet Weight

15kg/pcs

Display parameters

Optical

Brightness

≥2500cd/m2

Brightness adjustment

Red/Green and Blue4096Grade/Each

Viewing angle

H/V 140/140

Best viewing distance

1.5m-10m

Display color

16.7 million

Grey Scale

10bits/1024levels

Power

Max Power Consumption

1600w/m2

Ave Power Consumption

800m/m2

Working Voltage

AC 220V±10%

Control System

Frame Frequency

60-85HZ

Refresh Rate

1000-3000HZ

Color Temperature

5000-9300K

Signal Input

Composite /S-video/Component/VGA/DVI/HDMI/SDI/HD_SDI/etc

Controlling System

PCTV non-linear editting card+DVI display card+main controller+optical fiber transmission(optical)

Controlling Distance

By CAT5 Cable:100M/ Multi-Mode fiber: 500M/ Single-Mode fiber : 10 KM

Reliability

Working Temperature

-20+65

Working Humidity

10-90%RH

Life Span

100000hours

MTBF(Ave No Failure Time)

5000hours

Pixel Failing Rate

0.01%

IP rate

IP31

Arise Technology Co., Ltd. is a high-tech company dedicated in providing professional LED displays and comprehensive optoelectronic solutions.

Arise Technology owns strong execution, brilliant development strategies and programs, sustainable creation based on market demand. We spare no effort to provide customers with market-oriented innovative products with good reliability, suitable solutions and all-round service. Our main products includes indoor and outdoor full color fixed installation LED display, indoor and outdoor rental LED displays, LED Mesh/LED curtain displays, LED advertising player displays, floor LED displays, stadium/perimeter LED displays, creative LED displays, mobile LED displays, flexible LED displays, transparent LED displays, high-resolution full color LED display, customized LED displays, and the whole display system and equipment. We are ready to providing LED display solutions for oversea and domestic advertisement media, building advertising and lighting, municipal administration, hospital, hotel, bank, traffic, sports, entertainment, show, exhibition, etc.

We Arise Technology regard integrity in company staff, customers and suppliers as the enterprise foundations, market demands as the guide. We guarantee quality with profession and dedication and use enterprise culture to fill our brand. We keep striving, forging ahead, creating to provide customer with strong and unremitting support and backup.

We Arise Technology also have more LED displays for your projects:

• Outdoor fix installation LED displays: P4/P4.8/P5/ P6/ P6.67/ P8/ P10 (DIP)/ P10 (SMD)/ P10.4/ P12/ P16/ P20/ P25/ P31.25/ P40/ P50;

• Indoor fix installation LED displays: P1.6/ P1.667/ P1.8/ P1.875/ P1.9/ P2/ P2.5/ P3/ P3.9/ P4/ P4.8/ P5/ P6/ P6.67/ P7.62/ P8/ P10

• Outdoor Rental LED displays: P3.9/ P4.8/ P5/ P6/ P6.25/ P6.67/ P6.94/ P7.8/ P8/ P8.9/ P10

• Indoor Rental LED displays: P2/ P2.5/ P3/ P3.125/ P3.75/ P3.91/ P4/ P4.81/ P5/ P6/ P6.25/ P6.4/ P7.62/ P8/ P10

• Perimeter LED Displays: P6/ P8/ P10/ P12/ P12.5/ P16

• LED Advertising Player/Kiosk LED displays: P2.5/ P3/ P4/ P5/ P5.3/ P6

• Stair LED displays: P6/ P6.67/ P7.62/ P10/ P16/ P18/ P20

• Transparent LED display: p3.9/p7.81/p8/p10

• Led Street Screen: p4/p5/p6/p8

• LED Floor Tiles: P6.25/ P8.9/ P10.4

• LED ball: P3/ P4/ P5/ P6/ P7.62/ P8/ P10

• Led Stage Screen-DJ screen: P3/ P4 /P5/ P6

• Taxi LED banner signs: P4/ P5/ P6

• Bus LED banner signs: P5/ P6/ P7.62

• More customized LED displays.

P1.8mm Indoor LED video displays from high definition P1.2/P1.5/P1.8/P1.9 and P2.5/ P3.1/

We will be your best partner by providing you professional LED display products and service and support from China production base!! Should any LED display projects, please just feel free to contact!
