Specifications
Place of Origin :
CHINA
Brand Name :
ARISE
Certification :
ISO CE FCC ROHS
Model Number :
P5 Outdoor SMD LED Display,HD High Quality Waterproof P5 Outdoor SMD Advertising LED Display
Description

P5 Outdoor SMD LED Display,HD High Quality Waterproof P5 Outdoor SMD Advertising LED Display

Arise Technology Co., Ltd

Web:http://www.ariseled.com

QQ:1327078259 Skype:ariseled

http://i.youku.com/ariseled

Features

1. High stability with top level SMD LED 2727.

2. High definition with 40000 pixels per square meter.

3. High brightness above 7000nits.

4. Optional system for wired or wireless control.

P5 Outdoor SMD LED Display,HD High Quality Waterproof P5 Outdoor SMD Advertising LED Displ

Pixel Pitch(mm)

5

Pixel Density(pixels/㎡)

40000

Pixel Configuration

SMD

Brightness(nits)

6300

Viewing Angle(deg.)

140(Horizontal), 140(Vertical)

Grey Level(bit)

14

Refresh Rate(Hz)

1920

Panel Size(mm)

960(W)×960(H)

Panel Size(inch)

37.80(W)×37.80(H)

Panel Resolution(pixels)

192×192

Panel Material

Iron/Aluminum

Panel Weight(kg)

60

Module Size(mm)

240(W)×240(H)

Module Size(inch)

9.45(W)×9.45(H)

Module Resolution(pixels)

48×48

Protection Grade(Front/Rear)

IP65/IP54

Serviceability

Front/Rear

Voltage(V)

AC 110~AC 220

Avg.Power Consumption(W/㎡)

250(AC)

Max.Power Consumption(W/㎡)

750(AC)

Driving Mode

1/8 scan

Operating Temp/Humidity(℃/%RH)

-20~40/10~90

Storage Temp/Humidity(℃/%RH)

-40~60/10~80

Lifetime(Normal Temp)(hours)

≥50000

Arise Technology Co., Ltd. is a high-tech company dedicated in providing professional LED displays and comprehensive optoelectronic solutions.

Arise Technology owns strong execution, brilliant development strategies and programs, sustainable creation based on market demand. We spare no effort to provide customers with market-oriented innovative products with good reliability, suitable solutions and all-round service. Our main products includes indoor and outdoor full color fixed installation LED display, indoor and outdoor rental LED displays, LED Mesh/LED curtain displays, LED advertising player displays, floor LED displays, stadium/perimeter LED displays, creative LED displays, mobile LED displays, flexible LED displays, transparent LED displays, high-resolution full color LED display, customized LED displays, and the whole display system and equipment. We are ready to providing LED display solutions for oversea and domestic advertisement media, building advertising and lighting, municipal administration, hospital, hotel, bank, traffic, sports, entertainment, show, exhibition, etc.

We Arise Technology regard integrity in company staff, customers and suppliers as the enterprise foundations, market demands as the guide. We guarantee quality with profession and dedication and use enterprise culture to fill our brand. We keep striving, forging ahead, creating to provide customer with strong and unremitting support and backup.

We Arise Technology also have more LED displays for your projects:

Category Pixel Pitch(mm)

1. Outdoor Fix Installation LED Display Series P4/ P5/ P6/ P6.67/ P8/ P10 (DIP)/ P10 (SMD)/ P10.4/ P12/ P16

2. Outdoor Strip/Louver LED Display Series P15.625-15.625/ P15.625-31.25/ P31.25-31.25

3. Outdoor Rental LED display Series P3.9/ P4.8/ P5/ P6/ P6.25/ P6.67/ P6.94/ P7.8/ P8/ P8.9/ P10

4. Indoor Fix Installation LED display Series P1.2/P1.56/P1.6/ P1.667/ P1.8/ P1.875/ P1.9/ P2/ P2.5/ P3/

P3.9/ P4/ P4.8/ P5/ P6/ P6.67/ P7.62/ P8/ P10

5. Indoor Rental LED Display Series P2/ P2.5/ P3/ P3.125/ P3.75/ P3.91/ P4/ P4.81/ P5/ P6/

P6.25/ P6.4/ P7.62/ P8/ P10

6. Transparent LED Display Series P3.9-7.8/ P7.8-15.625/ P8/ P10

7. Floor LED Display Series P6.25/ P6.25 interactive floor LED display /P8.9/ P10.4

8. Perimeter LED Display Series P6/ P8/ P10/ P12/ P16

9. LED Advertising Player/Kiosk LED Display Series P2.5/ P3/ P4/ P5/ P5.3/ P6

10. Taxi/Bus Mounted LED Display Series P4/ P5/ P6/ P7.62

11. LED Ball Display Series P3/ P4/ P5/ P6/ P7.62/ P8/ P10

12. Multiple creative LED displays and DJ booth LED displays for clubs and stages.

• Stair LED displays: P6/ P6.67/ P7.62/ P10/ P16/ P18/ P20

• Led Street Screen: p4/p5/p6/p8

• LED Floor Tiles: P6.25/ P8.9/ P10.4

• Led Stage Screen-DJ screen: P3/ P4 /P5/ P6

• More customized LED displays.

P5 Outdoor SMD LED Display,HD High Quality Waterproof P5 Outdoor SMD Advertising LED Displ

We will be your best partner by providing you professional LED display products and service and support from China production base!! Should any LED display projects, please just feel free to contact!

Arise Technology Co., Ltd

One-stop LED display manufacturere

Web:http://www.ariseled.com

QQ:1327078259 Skype:ariseled

http://i.youku.com/ariseled
