Specifications
Place of Origin :
CHINA
Brand Name :
ARISE
Certification :
ISO CE FCC ROHS
Model Number :
Indoor die cast rental led 500mmx1000 P4.81 ,P5.95,P6.94 Indoor Rental LED Display,ARISELE
Description

Indoor die cast rental led 500mmx1000 P4.81 ,P5.95,P6.94 Indoor Rental LED Display

Indoor Rental Die-cast Aluminum LED Display with Dual Power and Slim Body, Noiseless Design,P4.81 ,P5.95,P6.94

Arise Technology Co., Ltd

One-stop LED display manufacturere

Web:http://www.ariseled.com

QQ:1327078259 Skype:ariseled

http://i.youku.com/ariseled

Indoor die cast rental led 500mmx1000 P4.81 ,P5.95,P6.94 Indoor Rental LED Display,ARISELE

【Product overview】:P4.81 indoor full color display, It is main made up of three colors: red, green and blue; Resolution 43264dots; Pixel Pitch 4.81mm; Cabinet size: 500mmx1000mm; Cabinet weight 10.5kg.


【Applications】:Shopping center, Hospital, Bank, Enterprise and public institution, Exhibition hall, Stadium, Ticket hall, Hotel, Security company, Shopping mall, Business, School, Stage, Bank, Security, Transportation, Commercial, Electricity, Customs, Hospital, Park, Airport, Auto show, TV station.

Technical Specification:

Modle No.

P4.81

Pixel Pitch

4.81mm

Pixel Configuration

1R1G1B

LED Encapsulation

SMD2427

Pixel Density

43264dots/㎡

Brightness

900-1100nit

Color Temperature

6500-9000k

Drive Mode

1/13

Cabinet Size(W*H*D)

500*1000*75mm

Cabinet Resolution

104*208

Cabinet Weight

10.5kg

Max Pqwer Consumption

≤520w/m2

Average Power Consumption

≤260w/m2

Best Viewing Angle

H:160° V:140°

Refresh Rate

1000--1920Hz

Grey Scale

14bit

Best Viewing Distance

8-50m

Protection Level

IP31

Cabinet Material

Die-casting Aluminum

Operation Voltage

110v/220v/47--63Hz

Working Humidity

10%-90%

Working Temperature

-20-+50℃

Technical Specification:

Modle No.

P5.95

Pixel Pitch

5.95mm

Pixel Configuration

1R1G1B

LED Encapsulation

SMD3528

Pixel Density

28224dots/m2

Brightness

900-1100nit

Color Temperature

6500-9500k

Drive Mode

1/7

Cabinet Size(W*H*D)

500*1000*75mm

Cabinet Resolution

84*168

Cabinet Weight

10.5kg

Max Pqwer Consumption

≤520w/m2

Average Power Consumption

≤260w/m2

Best Viewing Angle

H:160° V:140°

Refresh Rate

1000--1920Hz

Grey Scale

14bit

Best Viewing Distance

8-50m

Protection Level

IP65/IP54

Cabinet Material

Die-casting Aluminum

Operation Voltage

110v/220v/47--63Hz

Working Humidity

10%-90%

Working Temperature

-20-+50℃

Technical Specification:

Modle No.

P6.94

Pixel Pitch

6.94mm

Pixel Configuration

1R1G1B

LED Encapsulation

SMD3528

Pixel Density

20736dots/m2

Brightness

650-900nit

Color Temperature

6500-9000k

Drive Mode

1/9

Cabinet Size(W*H*D)

500*1000*75mm

Cabinet Resolution

72*144

Cabinet Weight

10.5kg

Max Pqwer Consumption

≤520w/m2

Average Power Consumption

≤260w/m2

Best Viewing Angle

H:160° V:140°

Refresh Rate

1000--1920Hz

Grey Scale

14bit

Best Viewing Distance

8-50m

Protection Level

IP65/IP54

Cabinet Material

Die-casting Aluminum

Operation Voltage

110v/220v/47--63Hz

Working Humidity

10%-90%

Working Temperature

-20-+50℃

Arise Technology Co., Ltd. is a high-tech company dedicated in providing professional LED displays and comprehensive optoelectronic solutions.

Arise Technology owns strong execution, brilliant development strategies and programs, sustainable creation based on market demand. We spare no effort to provide customers with market-oriented innovative products with good reliability, suitable solutions and all-round service. Our main products includes indoor and outdoor full color fixed installation LED display, indoor and outdoor rental LED displays, LED Mesh/LED curtain displays, LED advertising player displays, floor LED displays, stadium/perimeter LED displays, creative LED displays, mobile LED displays, flexible LED displays, transparent LED displays, high-resolution full color LED display, customized LED displays, and the whole display system and equipment. We are ready to providing LED display solutions for oversea and domestic advertisement media, building advertising and lighting, municipal administration, hospital, hotel, bank, traffic, sports, entertainment, show, exhibition, etc.

We Arise Technology regard integrity in company staff, customers and suppliers as the enterprise foundations, market demands as the guide. We guarantee quality with profession and dedication and use enterprise culture to fill our brand. We keep striving, forging ahead, creating to provide customer with strong and unremitting support and backup.

Indoor die cast rental led 500mmx1000 P4.81 ,P5.95,P6.94 Indoor Rental LED Display,ARISELE

We Arise Technology also have more LED displays for your projects:

Category Pixel Pitch(mm)

1. Outdoor Fix Installation LED Display Series P4/ P5/ P6/ P6.67/ P8/ P10 (DIP)/ P10 (SMD)/ P10.4/ P12/ P16

2. Outdoor Strip/Louver LED Display Series P15.625-15.625/ P15.625-31.25/ P31.25-31.25

3. Outdoor Rental LED display Series P3.9/ P4.8/ P5/ P6/ P6.25/ P6.67/ P6.94/ P7.8/ P8/ P8.9/ P10

4. Indoor Fix Installation LED display Series P1.2/P1.56/P1.6/ P1.667/ P1.8/ P1.875/ P1.9/ P2/ P2.5/ P3/

P3.9/ P4/ P4.8/ P5/ P6/ P6.67/ P7.62/ P8/ P10

5. Indoor Rental LED Display Series P2/ P2.5/ P3/ P3.125/ P3.75/ P3.91/ P4/ P4.81/ P5/ P6/

P6.25/ P6.4/ P7.62/ P8/ P10

6. Transparent LED Display Series P3.9-7.8/ P7.8-15.625/ P8/ P10

7. Floor LED Display Series P6.25/ P6.25 interactive floor LED display /P8.9/ P10.4

8. Perimeter LED Display Series P6/ P8/ P10/ P12/ P16

9. LED Advertising Player/Kiosk LED Display Series P2.5/ P3/ P4/ P5/ P5.3/ P6

10. Taxi/Bus Mounted LED Display Series P4/ P5/ P6/ P7.62

11. LED Ball Display Series P3/ P4/ P5/ P6/ P7.62/ P8/ P10

12. Multiple creative LED displays and DJ booth LED displays for clubs and stages.

• Stair LED displays: P6/ P6.67/ P7.62/ P10/ P16/ P18/ P20

• Led Street Screen: p4/p5/p6/p8

• LED Floor Tiles: P6.25/ P8.9/ P10.4

• Led Stage Screen-DJ screen: P3/ P4 /P5/ P6

• More customized LED displays.

We will be your best partner by providing you professional LED display products and service and support from China production base!! Should any LED display projects, please just feel free to contact!
