Outdoor P6 LED Display Parameters | |
Model | FO-6 |
Parameters | Speci. |
Pixel Pitch | 6mm |
Pixel Composition | 1R1G1B |
LED Type | 3-in-1 SMD3535 |
Display brightness | 7000cd/m² (adjustable) |
Color Temperature | 2500K to 10000K |
Viewing Angle | H: 160°; V:160° |
Pixel Density | 27777 pixels/m² |
Minimum Viewing Distance | ≥6 M |
Module Size | 192mm×192mm. |
Cabinet Size | W960mm×H960mm×D180mm |
Cabinet Weight | 46 kg/cabinet |
Cabinet Size | 0.9216 m² |
Cabinet Material | Iron |
Cabinet Aspect Ratio | 1:1 |
Cabinet Resolution | 160×160 pixels |
Grey Scale | 16bit(high refresh)、14bit(common refresh) |
Driving Mode | 1/8 scan, constant current |
Processing Depth | 65536 scales |
Colors | 281.4 trillion |
LED wave length | R: 620~630nm G: 520~535nm B: 465~475nm |
Brightness Control | Manual/Automatic |
Display contrast | 5000:1 |
Frame Rate | 50/60 Hz |
Refresh Rate | 3200 Hz(high refresh) 、1000 Hz(common refresh) |
Input Voltage | 110~220VAC±15% |
Input Power Frequency | 50~60 Hz |
p6 outdoor led display
FOB Price:US $0 - 3,750 / Square Meter
Min.Order Quantity:5 Square Meter/Square Meters sample order is available
Supply Ability:5000 Square Meter/Square Meters per Month
Port: FOB Shenzhen
Payment Terms:T/T
Quick Details
Place of Origin: | Shenzhen China (Mainland) | Brand Name: | ARISE | Model Number: | FO-6 |
Usage: | Outdoor | Tube Chip Color: | Full Color | Display Function: | Video |
Pixels: | 6mm | Screen Dimension: | 48x48mm | Pixel Pitch: | 6mm |
Physical Density (pixels/m2): | 27777 | LED Shape: | SMD3535 | Pixel Composition: | 1R1G1B |
Module Size: | 288x288mm | Module Resolution: | 48x48mm | Drive Mode: | 1/4 |
Packaging & Delivery
Packaging Detail: wooden case or flight case package
Delivery Detail: 20 - 25 days
Specifications
Die Casting Aluminum Cabinet Rental LED Display Outdoor
Outdoor SMD3535
PH6 6mm
Physical Density: 27777pixels/m2
P6 Die Casting Aluminum Cabinet Rental LED Display Outdoor
Small size, light weight, one hand taken available, fast and easy installation.
Die casting aluminium, high strength, hard to deformation.
High strength fast locking design, disassembly within 10 seconds, stable and secure.
Compatible with different pixels from P3 to P12 with the same size cabinet.
LED display Specification and Parameter
Pixel Pitch | 6mm | Ave. Power Consumption | 650W/m2 |
Physical Density | 27,777pixels/m2 | Operation Power Voltage | AC90V-260V 50-60HZ |
LED Shape | SMD3535 | Refresh Frame Frequency | 360-2000HZ |
Pixel Composition | 1R1G1B | Brightness Adjustment | 0-255 adjustable |
Module Size | 288x288 | Color Temperature | 3200-9300K |
Module Resolution | 48x48mm | Brightness Correction | A single LED, Single module, single-cabinet correction |
Drive Mode | Constant Current Drive 1/4 | Input Source Support: Composite | S-vide; Compoent: VGA, DVI, HDMI, SDI.HD_SDI |
Brightness | ≥5500 | Control Distance | UTP cable: 100m |
Contrast | ≥2000 : 1 | Operating Temperature | -40°-65° |
View Angle | 140°/140° | Operating Humidity | 10-90%RH |
View Distance | ≥6m | Operating Life | 100,000H |
Grey Scale | 65536 bit | MTBF | 50000H |
Color Capacity | 28.147billion | Protection Grade | IP65 |
Max Power Consumption | 1200W/m2 | Out of Control Rate | ≤0.01% |
LED screen features:
1. High resolution and high pixel density, true reproduction of high-definition images.
2. Color uniformity, high contrast, clear picture Octavia.
3. Precision die-cast aluminum housing, to achieve smooth seamless.
4. Flatness design, good heat dissipation, keeping silent.
5. Case lightweight, easy to transport and handling.
6. Edge locks and hanging quick design, easy installation.
7. High stability, high reliability, long life.
Specifications
P6 RGB Indoor Led Display:
1.High resolution
2.Long lifespan
3.High performance
4.Good quality
Arise Technology Co., Ltd Supply LED display all over the world with good quality and best prices.
Including: P1.2 P1.5 P1.8 P1.9 P2.5 P3 P4 P5 P6 P7.62 P8 P8.9 P10 P12 P16 P20 P25 P31.25 P50 full-color LED display screen, large LED advertising screen
Arise Technology Co., Ltd LED display products:
Outdoor Fix Installation LED Display :P6、P8、P10(DIP)、P10(SMD)、P12、P16、P20、P25
Indoor Fix Installation LED Display :P1.2 P1.8、P2.5、P3、P4、P5、P6、P7.62、P8、P10
Outdoor Rental LED Display :P6、P6.94、P8、P8.9、P10
Indoor Rental LED Display :P2.5、P3、P4、P5、P6、P7.62
Perimeter LED Display :P12、P16
Freeform & creative display
