P3.81mm, 1500 nits, SMD 2020 indoor led display Arise Technology Co., Ltd www.ariseled.com
Arise Technology Co., Ltd:
Email:gm@ariseled.com , Web:http://www.ariseled.com
QQ:2329518805 Skype:ariseled
Pixel pitch | 3.81 mm |
Module size | 244mm×244mm |
Driving method | 1/16 SCAN |
Pixel configuration | 1R1G1B |
LED type | SMD 2020 |
Drive IC | 16 bit constant current with current gain control |
Pixel / Module | 64x64 |
Cabinet dimensions | Width: 448mm |
Pixel density | 16,384 LEDs / Cabinet (128x128) |
Brightness | 1,500 nits |
Frame refresh rate | ≥60Hz |
Data refresh rate | 480Hz |
Power consumption | 1000 W/M2 (max) |
Hor. viewing angle | 120° |
Vert. viewing angle | 100°~120° |
Serviceability | Back |
I P grade | IP32 |
MTBF | ≥10000 hours |
Lifetime | 50,000 hours |
Pixel failure | < 0.0002 |
Operation power supply | 5V 60A |
Weight / Cabinet | 11 kg |
Applications requirements: high-definition, high refresh rate,high stability,no noise, light weight and easy to assemble and dismantle, high stability.
Applications: indoor hall, multi-functional conference hall, performance hall,command and control center, stage, theater.
Key benefits:
Ultra high-definition (68889 pixels / M2, 1280 * 768 HD screen can be realized by only 14.27 M2) screen with outstanding image and video quality.
High refresh rate (greater than 480 Hz) with software adjustable, suitable for filming.
High grayscale (14 bits) with superior color uniformity.
High contrast ratio (3000:1) with black mask and Black lens with black coating.
Wide viewing angle (greater than 140 ° in horizontal).
Die-casting aluminum cabinet with high mechanical precise, smooth and gapless surface.
Light weight (less than 11KG/ M2) with high strength.
Easy connection with novel rotatable lock
No noise due to fan-less.
Low power consumption (450 W/M2) thus less temperature increasing (less than 15℃).
High reliability and long lifespan (MTBF ≥ 5000 hours).
Optional for upgrade:
Ultra-High refresh rate (greater than 1200 Hz) with software adjustable, suitable for filming.
High grayscale (16 bits) with realistic visual performance.
On-site pixel by pixel brightness and color correction bring greater uniformity.
