Indoor P1.25 LED Display Parameters

Model

F I-1.25

Parameters

Speci.

Pixel Pitch

1.25mm

Pixel Composition

1R1G1B

LED Type

3-in-1 SMD (high contrast black LED)

Display brightness

600cd/m² (adjustable)

Color Temperature

2500K to 10000K

Viewing Angle

H: 160°; V:160°

Pixel Density

640000 pixels/m²

Minimum Viewing Distance

≥1.25M

Module Size

240mm×240mm

Cabinet Size

W480mm×H480mm×D70mm

Cabinet Weight

9 kg/cabinet

Cabinet Size

0.2304 m²

Cabinet Material

Die-cast aluminum

Cabinet Aspect Ratio

1:1

Cabinet Resolution

384 × 384 pixels

Grey Scale

16bit(high refresh),14bit(common refresh)

Driving Mode

1/32 scan, constant current

Processing Depth

65536 scales

Colors

281.4 trillion

LED wave length

R: 620nm; G: 520nm; B: 470nm.

Brightness Control

Manual/Automatic

Display contrast

5000:1

Frame Rate

50/60 Hz

Refresh Rate

3200 Hz(high refresh) ,1000 Hz(common refresh)

Input Voltage

110~220VAC±15%

Input Power Frequency

50~60 Hz

Max. Power Consumption

180W/cabinet

Ave. Power Consumption

60W/cabinet

Life Span

≥100,000 hours

Input Signal

RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc

Communication Collection

CAT5 Cable: ≤140m;

Multi-mode fiber ≤ 500m; Single mode fiber ≤ 20km )

Installation Method

Hanging /wall mounted/other customized installation methods.

Protection Scale

IP43

Operation Humidity

0℃~+45℃/10~90%RH

Storage Humidity

-10℃~+55℃/10~90%RH
