Outdoor P6.25 Stage LED Display Cabinet Die Casting Black Single Color LED Display
Outdoor P6.25 Stage LED Display Cabinet Die Casting Black Single Color LED Display
Specifications
Place of Origin :
CHINA
Brand Name :
ARISELED
Certification :
CE\CCC\ISO\UL\ROHS\FCC
Model Number :
Outdoor P6.25 Stage LED Display Cabinet Die Casting Black Single Color LED Display
Description

Outdoor P6.25 Stage LED Display Cabinet Die Casting Black Single Color LED Display

Arise Technology Co., Ltd

Email:gm@ariseled.com; Web:http://www.ariseled.com QQ:2329518805 Skype:ariseled

Product Details:

Place of Origin: Shenzhen China

Brand Name: ARISELED

Certification: CE/ISO9001/FCC/ROHS

Model Number: P6.25

Payment & Shipping Terms:

Minimum Order Quantity: 5sqm

Price: Negotiation

Packaging Details: Wooden Case / Flight Case

Delivery Time: 10-20 Working Days

Payment Terms: T/T, L/C

Supply Ability: >10000sqm/month

Outdoor P6.25 Stage LED Display Cabinet Die Casting Black Single Color LED Display

Detailed Product Description

Product Name: P6.25mm Led Display Cabinet 500X500 Alunimum Cabinet Pixel Pitch: 6.25mm

Size Of Panel: 250x250 Brightness: 5000

Usage: Advertising Pixel Density: 25600

Weight: 8.5 KG For Each Cabinet

specifications

1. Indoor led Display technical parameter

Pixel Density(pixel/㎡)

25600

White Balance Brightness (cd/㎡)

≥5000(adjustable)

Max Power Consumption

300W/cabinet

Average Power Consumption

150W/cabinet

Color Temperature

3200-9300(adjustable)

View Angle

Horizontal 110°；Vertical 110°

Display Work Method

1/10 scan

Digital Processing

14 bit

Gray Scale

65536 levels per color

Input Signal

Video: PAL/NTSC Option: VGA , Video , DVD,TV, SDI.HDMI etc

Waterproof

Yes

Working Temperature(ºC)

-20～+45

Humidity(RH)

10% - 80%

Stored Temperature (ºC)

-30～+60

Lifetime (50%Brightness)(Hours)

≥100,000

Input Voltage(VAC)

AC 220(or 110V)

Input Power Frequency(Hertz)

50 to 60

Data Connection

Super CAT6 Cable or Fiber

Operating System

Windows(98/2000/XP/Vista)

Blind Spot Rate

＜0.00001

Control Distance

CAT6 cable:150 meters; Single Fiber: Up To 10 Kilometers

Panel Input Format (With Video Processor)

VGA,DVI,RGBHV, PbPr (HDTV),Composite, S-Video, TV

Earth Leakage Current(mA)

＜2

2. Indoor LED Display Module

Pixel Configuration

SMD3535

Pixel Pitch

6.25 mm

Module Resolution

40 x 40

Module Size(W*H)

250mm x 250mm

Weigth Per Module

0.65kg

Max Power Consumption

50w

3. Indoor LED Display Cabinet

Cabinet Size(W*H)

500mm × 500mm

Module Qty

4 pcs

Cabinet Resolution

80 x 80

Cabinet Area

0.25㎡

Weight Of One Cabinet

8.5 kg

Cabinet Pixel

25600

Cabinet Flatness

＜0.2/㎡

Cabinet Material

Die Casting Cabinet

Applications:The LED display is widely used in public places, advertising, city road network, city parking lot, railway station and metro as well as other transportation guidance systems. and some hall.

competitive advantage

1. 24/7 online support service.

2. Every LED Product Is a Good Quality .

3. Every LED Product Will Have Better Price.

4. Red,Green And Blue LED Chips Incorporated Encapsulation ,Better Perspective.

5. Two Years Maintenance Service With Free.

Arise Technology Co., Ltd. 

is a hightech company dedicated in providing professional LED displays & comprehensive optoelectronic solutions.

Arise Technology owns strong execution, brilliant development strategies and programs, sustainable creation based on market demand. We spare no effort to provide customers with market-oriented innovative products with good reliability, suitable solutions and all-round service. Arise’s main products includes outdoor and indoor full color LED display, outdoor and indoor rental LED displays, stadium/perimeter LED displays, LED Mesh/LED curtain displays, creative LED displays, LED banner signs, high-resolution full color LED display, creative LED displays,customized LED displays, and the whole display system and equipment. We are ready to providing LED display solutions for oversea and domestic advertisement media, building advertising and lighting, municipal administration, hospital, hotel, bank, traffic, sports, entertainment, show, exhibition, etc.

We Arise Technology regards integrity in company staff, customers and suppliers as the enterprise foundations, market demands as the guide. We guarantee quality with profession and dedication and use enterprise culture to fill our brand. We keep striving, forging ahead, creating to provide customer with strong and unremitting support and backup.

Arise Technology Co., Ltd

Email:gm@ariseled.com; Web:http://www.ariseled.com QQ:2329518805 Skype:ariseled
