LED banner outdoor Full Color：P13.33/P16/P20
LED banner outdoor Full Color：P13.33/P16/P20
Specifications
Place of Origin :
CHINA
Brand Name :
ARISE LED
Model Number :
LED banner outdoor Full Color：P13.33/P16/P20
Certification :
ISO CE UL CCC FCE
Description

LED banner outdoor Full Color：P13.33/P16/P20

Arise Technology Co., Ltd.

Widely used in the outdoor environment

1.vivid images,fluent video.

2.adapt to bad outdoor environment,

3.excellent protective functions(no-load protection,short circuit protection,over-current protection,overheat protection)

LED banner outdoor Full Color：P13.33/P16/P20

Model

P13.33

Pixel Pitch

13.33mm

Module Size

320×160mm

Cabinet Size

960x960mm

Pixel Density

5627dots/㎡

Pixel Configuration

1R1G1B

Module Resolution

24×12

Module Power Consumption

8W

Optimum Viewing Distance

≥13.33.0m

Optimum Viewing Angle

12o°(H)/60°(V)

Max. Power Consumption

400W/㎡

Driving Mode

1/6Scan,Constant Current

Brightness of white balance

>3500Nits

Grey Scale/Color

16777216

Refresh Rate

≥400Hz,max2000Hz

Operating Environment

Temperature,-20℃~+50℃; Humidity, 10%~90%RH

Working Voltage

AC110V/220V ±10%

Model

P10

Pixel Pitch

10mm

Module Size

320*160mm

Cabinet Size

960*960mm

Pixel Density

10000dots/㎡

Pixel Configuration

1R1G1B

Module Resolution

32×16

Module Power Consumption

24.5W

Optimum Viewing Distance

≥10m

Optimum Viewing Angle

105°(H)/50°(V)

Max. Power Consumption

400W/㎡

Driving Mode

1/4 Scan, Constant Current

Brightness of white balance

≥5000 Nits

Grey Scale/Color

16777216

Refresh Rate

≥400Hz,max2000Hz

Operating Environment

Temperature,-20℃~+50℃; Humidity, 10%~90%RH

Working Voltage

AC110V/220V ±10%

LED banner outdoor Full Color：P13.33/P16/P20

Arise Technology Co., Ltd. is a high-tech company dedicated in providing professional LED displays and comprehensive optoelectronic solutions.

Arise Technology owns strong execution, brilliant development strategies and programs, sustainable creation based on market demand. We spare no effort to provide customers with market-oriented innovative products with good reliability, suitable solutions and all-round service. Arise’s main products includes outdoor and indoor full color LED display, outdoor and indoor rental LED displays, stadium/perimeter LED displays, LED Mesh/LED curtain displays, creative LED displays, LED banner signs, high-resolution full color LED display, creative LED displays,customized LED displays, and the whole display system and equipment. We are ready to providing LED display solutions for oversea and domestic advertisement media, building advertising and lighting, municipal administration, hospital, hotel, bank, traffic, sports, entertainment, show, exhibition, etc.

We Arise Technology regards integrity in company staff, customers and suppliers as the enterprise foundations, market demands as the guide. We guarantee quality with profession and dedication and use enterprise culture to fill our brand. We keep striving, forging ahead, creating to provide customer with strong and unremitting support and backup.
