Specifications
Place of Origin :
CHINA
Brand Name :
ARISE LED
Model Number :
Strip LED Display Glass wall P8 P10 P16 P20 P25 P31.25
Certification :
ISO CE UL CCC FCE
Description

Strip LED Display Glass wall P8 P10 P16 P20 P25 P31.25

Arise Technology Co., Ltd

Strip LED Display Glass wall P8 P10 P16 P20 P25 P31.25

Features

1) LED curtain Sign is a light weight, thin cabinet, features of thinness , seeing-through , to provide easy and fast implement with the friendly hardware/software interface.

2) It is designed for rental application and fixed installation both indoor and outdoor.

3) Using transparent screen designed, does not affect body ventilation and rear lighting, lighting uniformity, low wind resistance

4) Stages, clubs , live show, background and exhibition booths form the perfect environment for the meshes

5) Available for brightness adjustment with lightt-sensing control system , the screen can adjust the brightness according to the light of indoor or outdoor automatically which is also energy-saving for client

6) Highly Protective and Applicable to Rainy Weather

Strip LED Display Glass wall P8 P10 P16 P20 P25 P31.25

Pixel Pitch(mm)

H:5 V:8

P8

P10

P16

P20

P25

P31.25

Pixel density(dots/m2)

25,000

15,625

10,000

3,906

2,500

1,600

1,024

Pixel Configuration

SMD2121

SMD3528 or 3535

SMD3528 or 3535

SMD3535

SMD3535

SMD3535

SMD3535

Module size(mm)

5X640

960X320

960X320

512X256

640X320

400X400

500X250

Module resolution

1X80

120X40

96X32

32X16

32X16

16X16

16X8

Module configuration

256X1

1X3

1X3

2X4

2X4

3X3

2X4

Cabinet size(mm)

1280X640

960X960

960X960

1024X1024

1280X1280

1200X1200

1000X1000

Cabinet resolution

256X80

120X120

96X96

128X128

64X64

48X48

32X32

Transparency

45%

53%

60%

65%

70%

75%

80%

Brightness (cd/sqm)

≥3000

≥3000 or ≥6000

≥3000 or ≥6000

≥6500

≥5000

≥4500

≥3500

Power Consumption

Max:800W/sqm

Max:800W/sqm

Max:800W/sqm

Max:800W/sqm

Max:650W/sqm

Max:400W/sqm

Max:300W/sqm

Avg:250W/sqm

Avg:250W/sqm

Avg:250W/sqm

Avg:250W/sqm

Avg:200W/sqm

Avg:160W/sqm

Avg:100W/sqm

Protection Grade (Front/Rear)

IP65

IP42 or IP65

IP42 or IP65

IP65

IP65

IP65

IP65

Contrast Ratio

3000:1

Cabinet Weight

28kg/sqm(Aluminum Cabinet)

Power Supply

AC85~264V(50/60Hz)

Frame Rate

50Hz&60Hz

Refresh Rate

1500HZ

Lifetime(Half brightness)

100,000Hrs

Operating Temperatures

-10-60℃

Storage Temperatures

-20-60℃

Work humidity

10%-90%RH

Strip LED Display Glass wall P8 P10 P16 P20 P25 P31.25

Arise Technology Co., Ltd. is a high-tech company dedicated in providing professional LED displays and comprehensive optoelectronic solutions.

Arise Technology owns strong execution, brilliant development strategies and programs, sustainable creation based on market demand. We spare no effort to provide customers with market-oriented innovative products with good reliability, suitable solutions and all-round service. Arise’s main products includes outdoor and indoor full color LED display, outdoor and indoor rental LED displays, stadium/perimeter LED displays, LED Mesh/LED curtain displays, creative LED displays, LED banner signs, high-resolution full color LED display, creative LED displays,customized LED displays, and the whole display system and equipment. We are ready to providing LED display solutions for oversea and domestic advertisement media, building advertising and lighting, municipal administration, hospital, hotel, bank, traffic, sports, entertainment, show, exhibition, etc.

We Arise Technology regards integrity in company staff, customers and suppliers as the enterprise foundations, market demands as the guide. We guarantee quality with profession and dedication and use enterprise culture to fill our brand. We keep striving, forging ahead, creating to provide customer with strong and unremitting support and backup.
