High Temperature Melt Pressure Transmitter, Micro Sensor, Transducer, Transmitter
High Temperature Melt Pressure Transmitter, Micro Sensor, Transducer, Transmitter
Specifications
Place of Origin :
CHINA
Brand Name :
LIGENT
Model Number :
LP-9H
Description
Technical Specification Sheet
Range0~10bar~2000bar, 0~5MPa~300MPa
Overload0~10bar~2000bar, 0~5MPa~300MPa
Max .TemperatureLP-9H (320°C); LP-9H2(400°C); LP-9H3(500°C)
Process connection1/2″-20UNF; M14×1.5; M18×1.5; M22; G3/4 or as required
Accuracy±0.5%F.S.ThermocoupleLP-9H3 (pt100; E; J; K)
Power Supply24VdcElectronic connection6pin or 8pin
Output4-20mA; 0-5V; 0-10VRepeatability±0.2%F.S.
Features & ApplicationLP-9H, LP-9H2, LP-9H3 series transducer is a +/- 0.5% sensor ideal for melt pressure applications requiring high performance, simple installation, good repeatability and stability. Equipped with a 6 pin or a 8 pin connecter, the transducer/transmitter is completely interchangeable with other international resembling products, widely used in hot molding machines, chemical fiber machines, rubber and plastic film extruders, etc.
Product tags

high temperature pressure transducer

,

pressure transmitter for high temperature application

,

high temperature melt pressure sensor
