High-brightness lattice SUD320 Digital Ultrasonic Flaw Detector
High-brightness lattice SUD320 Digital Ultrasonic Flaw Detector
Specifications
Place of Origin :
China
Brand Name :
China Coal
Description

chinacoal05

High-brightness lattice SUD320 Digital Ultrasonic Flaw Detector Digital Ultrasonic Flaw Detector , Ultrasonic Flaw Detector

High-brightness lattice SUD320 Digital Ultrasonic Flaw Detector

Product Introduction

*Automated gain,Peak Hold and Peak Memory;

*Automated display precise flaw location(Depth d,level p,distance s,amplitude,sz dB,);

*Ten independence setup, any criterion can be input freely, we can work in the scene without test block;

*Big memory of 300 A graph and 30000 thickness value.

*Gate and DAC alarm;Acoustic-Optical alarm;

*RS232 port,communication with pc is easy;

*The embeded software can be online updated;

*Li battery, continue working time up to 7 hours;

*Other assistant function;

*Display freeze;

*Automated echo degree;

*Angles and K-value;

*Lock and unlock function of system parameters;

*Dormancy and screen savers;

*Electronic clock calendar ;

*Two gates setting and alarm indication;

*High-speed capture and very low noise;

*DAC,AVG; Solid metal housing (IP65);

*Provides high contrast viewing of the waveform from bright, direct sunlight to completae darkness and easy to read from all angles;

*Powerful pc software and reports can be export to excel;

Main Parameter

Designation

Technical Data

Range of scanning (mm)

Range of scanning (mm):2.5~60000(Steel Longitudinal wave)
Steps: 2.5,5,10,20, 30,40,50,60,70,80,90, 100,150,200, 250, 300, 350, 400, 450,500,600,700,800,900,1000,2000,3000,4000,5000,6000
Adjusting step: 0.1mm(2.5 mm~99.9mm),1mm(100mm~10000mm)

D-delay (ms)

D-delay (ms):-20~+3400

Steps: -20,-10,0.0, 10, 20, 50,100,150,200,250,300,350,400,450,500, 600,

700,800,900,1000,1500,2000,2500,3000,3400.

Adjusting steps: 0.1(-20ms~999.9ms),1(1000ms~3400ms)

P-delay (ms)

P-delay:0.0~99.99

Adjusting steps: 0.01

MTLVEL(m/s)

MTLVEL:1000~9999

7 fixed levels: 2260,2730,3080,3230,4700,5920,6300

Adjusting steps:1

Working mode

Single probe (receiving and sending), double probe (one for receiving and another for sending), transmission(transmission probe)

FrequencyRange (MHz)

0.4–20

Gain adjustment (dB)

0~110

Adjusting step: 0.0,0.2,0.5,1,2,6,12

Reject

0%~80% of screen height, step: 1%

Vertical linear error

Vertical linear error is not more than 3%

Horizontal linear error

Not more than 0.2% in the scanning range

Sensitivity Leavings

≥62 dB

Dynamic range

≥32dB

Alarm

Three modes, i.e. forbidden wave, loss wave and auto

Monitoring door

2, expressed by bold transverse line, whose start, width and height are adjustable.

Adjusting range of start (mm): horizontal pixel 0~208, the displayed value is relative with the scanning range.

Step: value in mm corresponding to a pixel (relative with the scanning range)

Adjusting range of width (mm): horizontal pixel 4~212, the displayed value is relative with the scanning range.

Step: value in mm corresponding to a pixel (relative with the scanning range)

Adjusting range of height: 2%~90% of vertical graduation

Step graduation: 1%

Display

Display: high-brightness lattice

A-Scan display area

Full screen or local

A-Scan display freezing and de-freezingA-Scan filling

Data save

300 A-Scan images (including setting of instrument)

30000 values of thickness (300 sets)

Standard interface

RS232 for communication with PC

Measuring unit

mm/inch

Battery

Li battery 4×3.6V4800mAh

Power adaptor

Input 100V~240V/50Hz~60Hz

Output 9V~12VDC/1.5A

Working temperature

-20°C~70°C

Working humidity

20%~90%

Port type

BNC

Dimension (mm)

240×180×50

Weight (kg)

1.8
