nema 17 Stepper Motor size 42mm Hybrid Stepper Motor ST42H309
nema 17 Stepper Motor size 42mm Hybrid Stepper Motor ST42H309
Specifications
Place of Origin :
China
Brand Name :
Sutai
Certification :
Iso900,CE,ROHS,TUV
Description

nema 17 Stepper Motor size 42mm Hybrid Stepper Motor ST42H309

ries Model Step angel Motor lengh Rated Current Phase Resistance Phase Inductance Holding torque Rotor Inertia Lead wire Motor weight
42H200 1.8 29 1 2 1.5 1.8 28 4 185
42H309 1.8 34 0.6 4.3 6.3 2.2 34 4 220
42H310 1.8 34 1 2.15 2.4 2.2 34 4 220
42H330 1.8 34 0.4 30 30 2.2 34 4 220
42H360 1.8 34 1 4.4 2.75 1.6 34 6 220
42H361 1.8 34 0.85 4.27 3.4 1.6 34 6 220
42H363 1.8 34 0.4 24.5 17 1.6 34 6 220
42H401 1.8 40 1.7 1.5 2.7 3.9 54 4 290
42H462 1.8 40 1.2 3.2 2.8 2.6 54 6 290
42H463 1.8 40 0.41 30 24 2.6 54 6 290
42H4812 1.8 48 1.2 3.2 4.2 4.4 68 4 360
42H4820 1.8 48 1.7 1.8 2.8 4.4 68 4 360
42H4861 1.8 48 1.26 4.2 3.9 3.2 68 6 360
42H4863 1.8 48 0.4 30 26.5 3.2 68 6 360
42H4866 1.8 48 0.8 7.6 8.4 3.2 68 6 360
42H640 1.8 60 0.64 15 13.2 6 82 4 450
42H643 1.8 60 2.1 1.6 3 6.5 82 4 450

All above are conventional products,we can also provide OEM service

nema 17 Stepper Motor size 42mm Hybrid Stepper Motor ST42H309

nema 17 Stepper Motor size 42mm Hybrid Stepper Motor ST42H309-+

Recommend driver

nema 17 Stepper Motor size 42mm Hybrid Stepper Motor ST42H309nema 17 Stepper Motor size 42mm Hybrid Stepper Motor ST42H309
