Concertina Razor Wire / Galvanized Concertina Razor Wire / Hight Security Razor Barbed Wir
Concertina Razor Wire / Galvanized Concertina Razor Wire / Hight Security Razor Barbed Wir
Specifications
Place of Origin :
CHINA
Brand Name :
FS
Certification :
ISO9001
Model Number :
FS
Description

Razor bared wire,plastic barbed wire,barbed wire,Hot dip galvanized razor wire,razor edge barbed wire,razor wire cbt-60,spiral razor barbed wire,plastic razor wire,razor barbed wire netting,razor barbed iron wire mesh,green razor barbed wire,concertina razor barbed wire

1.Materials:galvanized iron wire,PVC coated wire ,stainless steel wire and stainless steel sheet

2.Blade Type:BTO-12 BTO-18 BTO-22 CBT-60 CBT-65

3.Wire Dia.:2.0-2.5mm

4.Bard Length:10-65mm

5.Barb Spacing:26-100mm

6.Classification:straight line razor wire,concertina wire,crossed razor barbed wire,razor wire mesh

7.Process and Features:Galvanized steel plate or stainless steel plate punched into certain forms then attached to the steel wire in sharp angle to form the blades.The products offer beautiful appearance,economic cost,good frightening result and easy installation.Sharp blades coming in the form of concertina by buckles bring very good result of frightening and stopping to the aggressive perimeter intruders .

8.Applications:widely used in military field,prisons,detention houses,government buildings and other national security facilities.Also fencing of residences,villa wall and windows,express way,railway,national border lines,ets.

9.Specifications

Razor Blade Type and Specification
Reference Number Thickness Wire Diameter Barb Length Barb Width Barb Spacing
BTO-10 0.5 ± 0.05 2.5 ± 0.1 10 ± 1 13 ± 1 26 ± 1
BTO-12 0.5 ± 0.05 2.5 ± 0.1 12 ± 1 15 ± 1 26 ± 1
BTO-18 0.5 ± 0.05 2.5 ± 0.1 18 ± 1 15 ± 1 33 ± 1
BTO-22 0.5 ± 0.05 2.5 ± 0.1 22 ± 1 15 ± 1 34 ± 1
BTO-28 0.5 ± 0.05 2.5 ± 0.1 28 ± 1 15 ± 1 45 ± 1
BTO-30 0.5 ± 0.05 2.5 ± 0.1 30 ± 1 18 ± 1 45 ± 1
Outer diameter No. of loops Standard length per coil Type Notes
450mm 33 7m-8m CBT-65 Single coil
500mm 41 10m CBT-65 Single coil
700mm 41 10m CBT-65 Single coil
960mm 54 11m-15m CBT-65 Single coil
500mm 102 15m-18m BTO-12,18,22,28,30 Cross type
600mm 86 13m-16m BTO-12,18,22,28,30 Cross type
700mm 72 12m-15m BTO-12,18,22,28,30 Cross type
800mm 64 13m-15m BTO-12,18,22,28,30 Cross type
960mm 52 12m-15m BTO-12,18,22,28,30 Cross type
