China Cheapest Price Air Cooled Scroll Water Chiller Air Cooler
China Cheapest Price Air Cooled Scroll Water Chiller Air Cooler
Specifications
Place of Origin :
China
Brand Name :
MGREENBELT
Certification :
CE
Model Number :
MG-30C(D)
Product name :
Air cooler
Cooling capacity :
83.6kw
Input power :
32.33kw
Power supply :
3Phase-380V/415V/440V/460V/480V/-50HZ/60HZ
Refrigerant :
R22,R407c,R134a,R410a,R404a
Compressor :
Copeland,Danfoss,Sanyo
Water tank :
450L
Pump :
2.2kw
Compressor power :
1.32*2 kw
Water cooling chiller website :
http://www.mgchiller.com
Chiller support :
+86 18615626360
Description

China Cheapest Price Air Cooled Scroll Water Chiller Air Cooler

Company Introduction:

We are a quality cooperative partner in business,and also are the life friend in the long time friendship relation,so please do keep in touch with us,even though you have make the order or will make the order,thanks.

China Cheapest Price Air Cooled Scroll Water Chiller Air Cooler

China Cheapest Price Air Cooled Scroll Water Chiller Air Cooler

Technical Specification:

Model Unit MG-30C(D)
Nominal cooling capacity kcal/h 71896
KW 83.6
Input power KW 32.33
Power supply 3PH-380V-50HZ, others as request
Refrigerant Type R22/R134a/407c
Type of control Thermostatic expansion valve
Compressor Type Hermetic scroll
Power(kw) 9.05*4
Condenser Type Finned copper tube+low noise outer rotor fan
Cooling air flow(m3/h) 30000
Evaporator type Tank with coil/shell and tube
Chilled fluid flow(m3/h) 14.33
Volume(L) 450
Inlet and outlet pipe diameter(inch) DN65
Pump Power(kw) 2.2
Lift(m) 22
Dimension Length(mm) 2200
Wide(mm) 1160
High(mm) 1900
Weight kg 1150
Safety protection High/low pressure protection, anti-freeze protection of chilled water, power-phase sequence protection, phase-lack protection, the water-flow inadequate protection, overheating protection of compressor motor

TECHNICAL FEATURES

1). The machines uses brand compressor Sanyo,Copeland and Danfoss which can guarantee reliable running, high efficiency, low noise, power saving and long using life;

2).The highly effective heat exchanger(Stainless steel tank with coil or shell and tube type) minimizes the loss of cooling capacitywith simulation packing outside, It is easy to return oil.
The heating pipe is prevented from frost crack.
3). Adopt Protocol modbus 485 to support PLC control system.

4). Chiller set temperature range: 5-35C degree

5) Refrigerant options: R22,R407C,R134A,R410A.

China Cheapest Price Air Cooled Scroll Water Chiller Air Cooler

China Cheapest Price Air Cooled Scroll Water Chiller Air Cooler

China Cheapest Price Air Cooled Scroll Water Chiller Air Cooler

China Cheapest Price Air Cooled Scroll Water Chiller Air Cooler

Package of air cooler

1). Fumigation-free wooden case for each water chiller machine.

2). Chiller machine will send to Qingdao loading port if clients don't have any special requirements.

China Cheapest Price Air Cooled Scroll Water Chiller Air Cooler

Payment terms:

T/T: 50% Down payment, the balance before shipment, or you also can show us if any special required.

L/C,D/P,DDU and etc.

China Cheapest Price Air Cooled Scroll Water Chiller Air Cooler

Contact preson:Grace Zhang

Cell:0086 18615626360(calling,whatspp,viber,weichat)
Email:cnmgchiller@gmail.com
Skype:mb.gracezhang
Looking forward long and good cooperation from all over the world! MGREENBELT will give our agent price and good service.
