30 Ton Air Cooled Package Chiller Manufacture For Plastic
30 Ton Air Cooled Package Chiller Manufacture For Plastic
30 Ton Air Cooled Package Chiller Manufacture For Plastic
30 Ton Air Cooled Package Chiller Manufacture For Plastic
30 Ton Air Cooled Package Chiller Manufacture For Plastic
30 Ton Air Cooled Package Chiller Manufacture For Plastic
30 Ton Air Cooled Package Chiller Manufacture For Plastic
30 Ton Air Cooled Package Chiller Manufacture For Plastic
30 Ton Air Cooled Package Chiller Manufacture For Plastic
30 Ton Air Cooled Package Chiller Manufacture For Plastic
Specifications
Place of Origin :
China
Brand Name :
MGREENBELT
Model Number :
MG-40C(D)
Certification :
CE
Description

30 Ton Air Cooled Package Chiller Manufacture For Plastic

TECHNCIAL SPECIFICATIONS LIST

ModelUnitMG-40C
Nominal cooling capacitykcal/h94256
KW109.6
Input powerKW40.35
Power supply3PH-380V-50HZ(220V/440V/415V-50HZ/60HZ)
RefrigerantTypeR22/R134a/407c
Type of controlThermostatic expansion valve
CompressorTypeHermetic scroll
Power(kw)8.3*4
CondenserTypeFinned copper tube+low noise outer rotor fan
Cooling air flow(m3/h)40000
EvaporatortypeTank with coil/shell and tube
Chilled fluid flow(m3/h)18.87
Volume(L)580
Inlet and outlet pipe diameter(inch)3"
PumpPower(kw)3.75
Lift(m)22
DimensionLength(mm)2000
Wide(mm)1560
High(mm)1880
Weightkg1350
Safety protectionHigh/low pressure protection, anti-freeze protection of chilled water, power-phase sequence protection, phase-lack protection, the water-flow inadequate protection, overheating protection of compressor motor

TECHNICAL FEATURES

1). The machines uses brand compressor Sanyo,Copeland and Danfoss which can guarantee reliable running, high efficiency, low noise, power saving and long using life;

2).The highly effective heat exchanger(Stainless steel tank with coil or shell and tube type) minimizes the loss of cooling capacitywith simulation packing outside, It is easy to return oil.
The heating pipe is prevented from frost crack.
3). Adopt Protocol modbus 485 to support PLC control system.

4). Chiller set temperature range: 5-35C degree

5) Refrigerant options: R22,R407C,R134A,R410A

30 Ton Air Cooled Package Chiller Manufacture For Plastic30 Ton Air Cooled Package Chiller Manufacture For Plastic30 Ton Air Cooled Package Chiller Manufacture For PlasticAPPLICATION

It is widely used in many industries, including Plastic injection molding industry,chemical,paper making industry,electronics, pharmacy, food processing industry, aluminum profiles, aluminum alloys, tempering glass, coated glassindustry, CNC machinery industry,laser technology, laser technology, jewelry processing, leather processing, cultivation industry and so on.

30 Ton Air Cooled Package Chiller Manufacture For PlasticIf any further questions or inquiry please contact with us:

Ms Grace Zhang

Ph:+86018615626360

Skype:mb.gracezhang

Email:mg.chillers at gmail.com
