60BLF3A50 24VDC 3000RPM 0.25N.M 78W Brushless DC Motor
60BLF3A50 24VDC 3000RPM 0.25N.M 78W Brushless DC Motor
Specifications
Place of Origin :
Changzhou
Brand Name :
Changyi
Certification :
GSG is9000
Model Number :
60BLF3A50-243
Voltage :
24v
Rated speed :
3000rpm
Rated torque :
0.25N.m
Power :
78w
Current :
4.3A
Weight :
0.85kg
Length :
78mm
Description

Brushless DC Motor

60BLF3A50-243

Specification:

MODEL

60BLF3A50-243

Voltage (VDC)

24

Rated speed(rpm)

3000

Rated torque(N.m)

0.25

Rated current(A)

4.3

Power(W)

78

Peak torque(N.m)

0.75

Torque constant(N.m/A)

0.056

Length(mm)

78

Weight(kg)

0.85

Remark:

1. We can produce motor according to customer's requirements.

2. Motor can add gear box.
