More than 10 years experience in this industrial. Advanced production equipment, Efficient production efficiency, Perfect quality management system, A strong after-sales service, we are your prefect supplier.
MAIN APPLICATION:
*Electric vehicle ,such as electric bicycle ,electric car ,golf car
*Ups system
*Weighing apparatus: electronic balance
*Electric system ,Telecommunication system
*Solar system ,Wind system : solar light
*Security system : entrance guard system, monitor, emergency light
*Financial institutions : bank ,medical equipment , transportation equipment
*Electric toy car
*Electric sprayer ,lawn mower
FEATURE
* Completely sealed structure to avoid leakage for maintenance, flexible direction.
* Good performance and strong charging and discharging capability under low temperature
* Delivery with acid and fully charged ready for immediate use
* With super pure raw material, big capacity and low rate auto-discharging
* Good looking design
* High quality industrial plastic material for safety and easy maintenance
* Made of special lead calcium alloy makes better corrosion resistance and higher recovery capacity
* Good quality, safety, no leakage and no pollution, and it can be used at places
* More adaptable of environment and with long service life
* With good and most competitive price
* Delivery the goods on time
* Environmental friendly, reliable sealed structure, no leakage and no acid mist
*.High capacity :low internal resistance and super charging efficiency
*.Long life : cycle can reach more than 360 times in 25 degrees
*Consistency :using high purity raw materials ,patent lead paste recipe ,consistent capacity
*Free maintenance
STRUCTURE:
Component ...Raw material
Sealant .....Epoxy Resin
Positive .....Lead dioxide
Safety valve ..EPDR
Negative .....Lead
Container .....ABS
Separator .....Fiber glass
Cover .....ABS
Electrolyte ....Sulfuric acid
Terminal ........Pb Alloy.
WARING:
*To prevent the sun
* Avoid short circuit
*Don't charge in sealed container
*Ask professional person maintain
*Risk of fire explosion or burns
*Forbidden children and minors to contact battery
Regular sizes of VRLA battery:
ups battery type | Nominal voltage | Nominal capacity | size (mm)_ | weigh(kg) | ||
length | width | high | ||||
2-FM-4 | 4V | 4AH | 42 | 42 | 106 | 0.39 |
3-FM-4 | 6V | 4AH | 70 | 47 | 103 | 0.58 |
3-FM4.5 | 4.5AH | 70 | 47 | 103 | 0.64 | |
3-FM-5 | 5AH | 70 | 47 | 103 | 0.71 | |
3-FM-7 | 7AH | 151 | 35 | 99 | 1.01 | |
3-FM-12 | 12AH | 151 | 50 | 100 | 2 | |
6-FM-1.3 | 12V | 1.3AH | 97 | 47.5 | 55 | 0.55 |
6-FM-4 | 4AH | 90 | 70 | 104 | 1.44 | |
6-FM-7 | 7AH | 151 | 65 | 99 | 1.85 | |
6-FM-7 | 7AH | 151 | 65 | 99 | 2 | |
6-FM-7 | 7AH | 151 | 65 | 99 | 2.1 | |
6-FM-7 | 7AH | 151 | 65 | 99 | 2.25 | |
6-FM-10 | 10AH | 151 | 99 | 96 | 3.85 | |
6-FM-12 | 12AH | 151 | 99 | 96 | 3.35 | |
6-FM-12 | 13AH | 151 | 99 | 96 | 3.5 | |
6-FM-18 | 18AH | 181 | 77 | 166 | 5 | |
6-FM-18 | 18AH | 181 | 77 | 166 | 5.5 | |
6-FM-24 | 24AH | 166 | 175 | 126 | 7.6 | |
6-FM-24 | 24AH | 166 | 175 | 126 | 8 | |
6-FM-26 | 26AH | 166 | 126 | 174 | 8.1 | |
6-FM-28 | 28AH | 197 | 166 | 174 | 8.1 | |
6-FM-28 | 28AH | 197 | 166 | 174 | 9 | |
6-FM-38 | 38AH | 196 | 166 | 175 | 13 | |
6-FM-40 | 40AH | 197 | 166 | 174 | 12.6 | |
6-FM-40 | 40AH | 197 | 166 | 174 | 13 | |
6-FM-55 | 55AH | 227 | 137 | 210 | 16.2 | |
6-FM-55 | 55AH | 227 | 137 | 210 | 19 | |
6-FM-65 | 65AH | 350 | 166 | 174 | 20.5 | |
6-FM-80 | 80AH | 306 | 168 | 226 | 23 | |
6-FM-80 | 12V | 80AH | 306 | 168 | 226 | 23.5 |
6-FM-100 | 100AH | 407 | 174 | 209 | 28.5 | |
6-FM-100 | 100AH | 407 | 174 | 209 | 30 |
