Specifications
Place of Origin :
China
Brand Name :
CHUANG NAI
Model Number :
6-FM-12
Certification :
CE,ISO,SGS
Size :
151*99*96mm
Weight :
4.1kg
Description

More than 10 years experience in this industrial. Advanced production equipment, Efficient production efficiency, Perfect quality management system, A strong after-sales service, we are your prefect supplier.
MAIN APPLICATION:
*Electric vehicle ,such as electric bicycle ,electric car ,golf car
*Ups system
*Weighing apparatus: electronic balance
*Electric system ,Telecommunication system
*Solar system ,Wind system : solar light
*Security system : entrance guard system, monitor, emergency light
*Financial institutions : bank ,medical equipment , transportation equipment
*Electric toy car
*Electric sprayer ,lawn mower
FEATURE
* Completely sealed structure to avoid leakage for maintenance, flexible direction.
* Good performance and strong charging and discharging capability under low temperature
* Delivery with acid and fully charged ready for immediate use
* With super pure raw material, big capacity and low rate auto-discharging
* Good looking design
* High quality industrial plastic material for safety and easy maintenance
* Made of special lead calcium alloy makes better corrosion resistance and higher recovery capacity
* Good quality, safety, no leakage and no pollution, and it can be used at places
* More adaptable of environment and with long service life
* With good and most competitive price
* Delivery the goods on time
* Environmental friendly, reliable sealed structure, no leakage and no acid mist
*.High capacity :low internal resistance and super charging efficiency
*.Long life : cycle can reach more than 360 times in 25 degrees
*Consistency :using high purity raw materials ,patent lead paste recipe ,consistent capacity
*Free maintenance
STRUCTURE:
Component ...Raw material
Sealant .....Epoxy Resin
Positive .....Lead dioxide
Safety valve ..EPDR
Negative .....Lead
Container .....ABS
Separator .....Fiber glass
Cover .....ABS
Electrolyte ....Sulfuric acid
Terminal ........Pb Alloy.
WARING:
*To prevent the sun
* Avoid short circuit
*Don't charge in sealed container
*Ask professional person maintain
*Risk of fire explosion or burns
*Forbidden children and minors to contact battery
Regular sizes of VRLA battery:

ups battery typeNominal voltageNominal capacitysize (mm)_weigh(kg)
lengthwidthhigh
2-FM-44V4AH42421060.39
3-FM-46V4AH70471030.58
3-FM4.54.5AH70471030.64
3-FM-55AH70471030.71
3-FM-77AH15135991.01
3-FM-1212AH151501002
6-FM-1.312V1.3AH9747.5550.55
6-FM-44AH90701041.44
6-FM-77AH15165991.85
6-FM-77AH15165992
6-FM-77AH15165992.1
6-FM-77AH15165992.25
6-FM-1010AH15199963.85
6-FM-1212AH15199963.35
6-FM-1213AH15199963.5
6-FM-1818AH181771665
6-FM-1818AH181771665.5
6-FM-2424AH1661751267.6
6-FM-2424AH1661751268
6-FM-2626AH1661261748.1
6-FM-2828AH1971661748.1
6-FM-2828AH1971661749
6-FM-3838AH19616617513
6-FM-4040AH19716617412.6
6-FM-4040AH19716617413
6-FM-5555AH22713721016.2
6-FM-5555AH22713721019
6-FM-6565AH35016617420.5
6-FM-8080AH30616822623
6-FM-8012V80AH30616822623.5
6-FM-100100AH40717420928.5
6-FM-100100AH40717420930
