High quality 5006 350kv rc small helicopter motor multicopter outrunner electric brushless dc motor
High quality 5006 350kv rc small helicopter motor multicopter outrunner electric brushless dc motor
Specifications
Place of Origin :
shenzhen
Brand Name :
Brotherhobby
Model Number :
BHM5006
Certification :
CE, ROHS
Style :
Radio Control Toy
Power :
battery
KV :
350
Item :
brushless dc motor
No.of Cells( Lipo) :
3-6s
Stator Length :
7mm
Shaft Diameter :
6mm
Motor Dimension( DiaxL) :
50X25mm
Material :
metal
Type :
Multicopter
Description

High quality 5006 350kv rc small helicopter motor multicopter outrunner electricbrushless dc motor

Design feature:

1. Long life of Japan NMB ball bearings.

2. Efficient Japanese Kawasaki stator steel.

3. Rare earth magnets stable up to 180°.
4. Anaerobic pure copper wires.
5. CNC machining aluminum alloy shell.
6. The Silicone wire leads.
7. The balance of the patent technology.
8. The Unique connection method.

5006 Multicopter brushless motor

Technical Datas
KV350Idle Current @ 10.0V0.3A
Configu-ration24N28PNo.of Cells( Lipo)3-6S
Stator Diameter41mmMax continuous Current (A) 60S20A
Stator Length7mmMax continuous Power (W) 60S400W
Shaft Diameter6mmMax efficiency>84%
Motor Dimension( DiaxL)50X25mmInteral resistance0.280ohms
Net Weight( g )115gRecom. Speedcontroler25A
Tested with 25A ESC
PropVolts (V)Amps (A)Watts (W)Thrust (g)Thrust (oz)Efficienc (g/W)Efficienc (oz/W)
13X6.5(APC)22.27.1157.62134047.278.500.30
13X4(APC)22.26.6146.52122043.038.330.29
14X7(APC)18.57.8144.3130045.869.010.32
22.210.0222180063.498.110.29
