Specification
Ring Die Wood Pellet Mill/ Pellet Machine
1.Stable workability
2.Multi-using&short delivery time
3.Competitive price
4.Simple operation&maintenance
CE ISO Approval Wood Pellet Mill/ Pellet Machine
Brief introduction of the wood pellet machine
The ring die wood pellet making machine belongs to pellet fuel processing equipment. After the materials like sawdust,wood chips, wood logs, rice husk, sunflower seed shells, peanut shells, and other kinds of agricultural wastes are first ground by a hammer mill and dried to a moisture content about 15% , they can be processed by our ring die pellet machine into solid biomass pellets. The final wood pellets can be used in stoves for home heating and industrial boilers and large power plants. Besides, the pellets are also widely used for animal bedding.
Working principle of the ring die wood pellet machine
After grinding and drying process, the materials will be sent into feeding device and mixed in the conditioner. Then they are forced into the pelletizing chamber by the imperative feeder. In the chamber, materials are squeezed between the rollers and die to form into cylinder shape pellets. As they are extruded, cutting knives will cut the pellets into specified size.

Main advantages of the ring die wood pellet mill

a. Adopt high precision gear drive. Output is 20% larger than that of belt drive.
b. Advanced bearing and oil seal guarantee a efficient and stable working process.
c. Feeding device adopts frequency conversion motor, ensuring continuous and even feeding.
d. Different hole diameters make various sizes of pellets possible.
e. Flexible coupling shaft with novel structure ensures a stable pelletizing process and low breakdown possibility.
f. Permanent magnet device can remove impurities in the pelletizing process.
Raw materials required

Flow chart:

1). Crusher (to crush the materials into sawdusts or powders);

2). Dryer (to remove the moisture in materials );

3). Pellet mill (to press the materials into pellets, with sizes from 2 - 30mm, up to you);

4). Cooling machine (to cool down the output pellets and remove some moisture);

5). Sieving machine (to remove the dusts and broken pellets);

6). Packing machine (to put the pellets into bags of required sizes).

If you are interested in our wood pellet mill, pls contact me without hesitation, I will do whatever I could to help you, looking forward to hearing from you!
