Model

KM-IP4000

Video Compression

Operation System

H.264 Baseline profile

Video

Image Sensor

1.0MP HD CMOS Sensor

Core Chipset

Hi3518E Chipset

Resolution

720P HD images, resolution up to 1280x720,1.0MP

Resolution Variable

720P(1280 x 720),VGA(640 x 360), QVGA(320 x 180)

Frame Rate

1~30fps

Min. Illumination

Color: 1.5 Lux; W/B: 0 Lux with IR LED ON

IR Distance

Dual IR cut filter with auto switch,1pcs high-power ceramic IR LEDs, night vision at 5 meters

S/N Ratio

≥38dB

CMOS Features

Support AWB,AGC,BLC

Lens/Visual Angel

3.6mm mega-pixel lens@F1.４/56.14˚

System Feature

Security

Account, password two level user authentication

Adaptive dynamic IP domain name system(Free)

No need domain name, support dynamic IP, no application of “peanut shells”, completely solve the problem of frequently dropped calls, connection with high speed

Mobile phone monitor

Support megapixel HD mobile phone monitor, dedicated IPHONE software, Android software(Software version required IOS4.3,Android 2.3 and above)

On-board storage

Support external 128GB TF card,24 hours recording,More than 32GB need to be formatted as FAT32

Plug and Play

Adopting advanced Cloud-link P2P (Plug and play) technology, network penetration up to 99%, applicable to all kinds of complex networks, installation takes only three steps: 1. Connecting power supply and network, 2. Installing mobile phone software; 3. Viewing CCTV images.

Server Clusters

P2P intelligent clusters of servers throughout the world, protect the pan-tilt home IP camera works stable and efficient

Audio

Audio Compression:

G.711A

Audio Input

1CH built-in 38dB microphone

Audio Output

Built-in two speaker(8Ω1W)

Video Management

Recording Mode

Manual recording, timing recording and alarm recording

Video Storage

TF Card (support Max.128G)

Network

Ethernet

10Base -T, /100Base-TX, RJ45 Connector

Protocols

TCP/IP,HTTP,TCP,UDP,SMTP, DHCP,DNS,DDNS,NTP,UPnP,P2P etc

Wireless

WiFi 802.11b/g/n wireless network

Alarm

Motion Detection

Support

Alarm Action 1

Speaker alarm and call 5 different mobile phones

Alarm Action 2

Capture photos and send by E-mail

System Requirement

System Configuration

Software version IOS4.3,Android 2.3 and above

General

Material

Cartoon robot/engineering plastics

Working Environment

Indoor

Power Supply

DC5V 2A

Working Temperature

-10~50 °C

Working Humidity

95% RH

Standard Accessories

power adaptor, Bracket panel and Operation guide

Accessories Optional

Wireless door contact and Controller

Installation Method

Mounted on bracket or Flat type
